Sirius 800 www.snellgroup.com Module Compatibility
Issue 1 Rev 1 Page 35 © 2014 Snell Limited
5. Module Compatibility
For full details of the modules and their locations in the router frames see the Sirius 800 user
manual. This section list compatibility between modules and rear panels as well as the router
controllers and fan out modules.
5.1 Front Module and Rear Panel Compatibility
Table 9. shows the front module and rear panels that are currently ordered and shipped for
new Sirius 800 router systems.
Table 10. shows the front module and rear panels that were originally shipped with earlier
Sirius 800 router systems. These can still be supplied for use when expanding the router or as
replacements if required.
• A Sirius 800 router can contain a mix of front modules from Table 9. and Table 10.
as long as the correct rear panels are used for each front module.
• All modules in Table 9. and Table 10. will work with any of the video crosspoint
modules.
• The 5901 and 5905 video crosspoint module variants can be mixed in a frame.
Modules and Rear Panels Currently Ordered and shipped
Front Module Rear Panel
4915*
Sirius 800 AES/MADI input module
120 AES Pairs and up to 3 MADI Inputs
(MADI inputs not supported by 1299 and
1297 rear panels)
Sirius 830:
1354 Balanced AES rear panel
1357 Unbalanced AES rear panel
1299 Balanced AES rear panel
Sirius 840/850:
1352 Balanced AES rear panel
1355 Unbalanced AES rear panel
1297 Balanced AES rear panel
or
12 MADI (Main & Redundant)
Sirius 830:
1303 BNC rear panel
1304 Fiber rear panel
Sirius 840/850:
1285 BNC rear panel
1286 Fiber rear panel
4929*
Sirius 800 AES/MADI output module with
audio delay
120 AES Pairs and up to 3 MADI outputs
(MADI outputs not supported by 1298 rear
panel)
1353 Balanced AES rear panel
1356 Unbalanced AES rear panel
1298 Balanced AES rear panel
or
12 MADI (Main & Redundant)
1295 BNC rear panel
1296 Fiber rear panel
5917
Sirius 800 Standard Video BNC/Fibre input
module
Sirius 830:
1234/1235 BNC rear panel
1236 Fiber rear panel
Sirius 840/850:
1349/1289 BNC rear panel
1305 Fiber rear panel
Table 9. New Router Systems - Front Module and Rear Panel Compatibility
