Sirius 800 www.snellgroup.com Power Supply and Fan Maintenance
Issue 1 Rev 1 Page 29 © 2014 Snell Limited
Sirius 840/850 Replacement Rear Fans
Sirius 840/850 Rear View
Mark 1 Frame
Configuration
Mark 2 Frame
Configuration
Mark 3 Frame
Configuration
Fan Spare Part Numbers
Expansion Rear Fans (Sirius 850 only)
4 x FGAEY
1270C
4 x FGAEY
1270C
4 x FGAEY
6081270
Multiviewer Rear Fans (Sirius 840/850)
4 x FGAEY
1270C
4 x FGAEY
6080890 Y
4 x FGAEY
6081280
Lower Crosspoint Rear Fans (Sirius 840/850)
4 x FGAEY
1270C
4 x FGAEY
6080890 Y
4 x FGAEY
6081280
Table 8. Sirius 840/850 Rear Fan Part Numbers
