Sirius 800 www.snellgroup.com Module Compatibility
Issue 1 Rev 1 Page 37 © 2014 Snell Limited
5915*
Sirius 800 Video AHP input module
Sirius 830:
1234/1235 BNC rear panel
1236 Fiber rear panel
Sirius 840/850:
1349/1289 BNC rear panel
1305 Fiber rear panel
5916
Sirius 830 Standard Video BNC/Fiber input
module
1234/1235 BNC rear panel
1236 Fiber rear panel
5923
Sirius 840/850 Standard Video BNC output
module
1295 BNC rear panel
5924
Sirius 840/850 Standard Video Fiber output
module
1296 Fiber rear panel
5925*
Sirius 800 Video AHP output module 1294 BNC rear panel
1302 Fiber rear panel
5937
Sirius 830 Standard Video BNC/Fiber
output module
1294 BNC rear panel
1302 Fiber rear panel
Modules and Rear Panels shipped with Earlier Router Systems
Front Module Rear Panel
Table 10. Original Router Systems - Front Module and Rear Panel Compatibility
