Sirius 800 www.snellgroup.com Crosspoint Faults and Replacement
Issue 1 Rev 1 Page 63 © 2014 Snell Limited
Presence Green = Crosspoint module present
Red = Crosspoint module not present
Power Green = Crosspoint module is powered
Red = Crosspoint module is not powered
More button Displays the Modules screen, see the Sirius 800 User manual for
details.
Free Failed Crosspoint
button
Moves all of the routes from the failed crosspoint module to the
redundant crosspoint module allowing the failed crosspoint
module to be replaced. The “Active” LED on the failed crosspoint
module will go off.
The failed crosspoint card can be replaced without interrupting
any crosspoint routing once the routes have been switched to the
redundant crosspoint module.
Sirius 830 Crosspoint Card Status Buttons
XpntCardRedundant830
button
Touch the button to bypass the redundant crosspoint card.
Grey = Redundant crosspoint card is working correctly.
Yellow = Redundant crosspoint card has failed or been
bypassed.
XpntCardMain830 button Touch the button to bypass the main crosspoint card.
Grey = Main crosspoint card is working correctly.
Yellow = Main crosspoint card has failed or been bypassed.
Sirius 840/850 Crosspoint Card Status Buttons
XpntCardOddToOdd_1
button
Touch the button to bypass crosspoint card 1.
Grey = Crosspoint card 1 is working correctly.
Yellow = Crosspoint card 1 has failed or been bypassed.
XpntCardEvenToOdd_2
button
Touch the button to bypass crosspoint card 2.
Grey = Crosspoint card 2 is working correctly.
Yellow = Crosspoint card 2 has failed or been bypassed.
XpntCardRedundant_R
button
Touch the button to bypass the redundant crosspoint card.
Grey = Redundant crosspoint card is working correctly.
Yellow = Redundant crosspoint card has failed or been
bypassed.
XpntCardOddToEven_3
button
Touch the button to bypass crosspoint card 3.
Grey = Crosspoint card 3 is working correctly.
Yellow = Crosspoint card 3 has failed or been bypassed.
XpntCardEvenToEven_4
button
Touch the button to bypass crosspoint card 4.
Grey = Crosspoint card 4 is working correctly.
Yellow = Crosspoint card 4 has failed or been bypassed.
Screen Item Description
Table 15. Video Crosspoint Matrix Status Screen
