Sirius 800 www.snellgroup.com Crosspoint Faults and Replacement
Issue 1 Rev 1 Page 65 © 2014 Snell Limited
Red
Command
Error
Error with command from
the Control module
Off - normal state
Flashing - the command message
from the router controller is corrupt or
hasn’t been received. If all of the
crosspoint modules indicate a
Command Error check that the router
controller is operating correctly. If only
one of the crosspoint modules
indicates the error contact Snell
Customer Support (see section 1.2 for
contact details).
Yellow
Switch Flashes on a take signal
when switching a route
Off - normal state
Flashes - each time a route is set
Blue/Green
Fugue
Status
(5905 only)
CPU status
The LED is approximately
25 mm (1 Inch) from the
edge of the board.
Flashing Green, Green, Blue -
normal operation, the CPU is
programmed and running
Brief Flash Red at startup - normal
Flashing Red - CPU error. Remove
module and refit to force a reboot.
Red
Xpt Alarm
(5905 only)
Xpt Error
(5901 only)
Displays if there is a
problem with any
crosspoints
Off - normal state
On solid - problem with one or more
crosspoints on the module.
Flashing - Crosspoint module
overheating, make sure the fan
assemblies are all closed and the fans
are all operating correctly.
Yellow
Active Route is active on
crosspoint
Flashing - when this module is routing
one or more signals to live outputs.
Removing the crosspoint module will
disturb the signal(s) passing through
the crosspoint module.
Red
Route Fail Illuminated if a route failure
has been detected on this
crosspoint
Off - normal state
Flashing - receiving error messages
related to a route failure
LED Color Label Detail Status
Table 16. Video Crosspoint Module LED Information
