13.1.8. RECTIFIER PARAMETERS TABLE
“Input Parameters”
“Input Voltage (V)”
Per phase
“Input Current (A)”
Present if computed by UPS
“Input Power (kW)”
Present if computed by UPS
“Input Frequency (Hz)”
“Gen Set Status”
Present if managed by UPS
13.1.9. BYPASS PARAMETERS TABLE
“Bypass Parameters”
“Bypass Voltage (V)”
Per phase
“Bypass Compound Voltage (V)”
Present if computed by UPS
“Bypass Power (kW)”
Present if computed by UPS
“Bypass Frequency (Hz)”
13.1.10. INVERTER PARAMETERS TABLE
“Inverter Parameters”
“Inverter Voltage (V)”
Per phase. Set to 0 if inverter is off
“Inverter Compound Voltage (V)”
Present if computed by UPS
“Inverter Frequency (Hz)
Set to 0 if inverter is off
