appendix: net vision 7 trap desCription
upsTraps(2) No. Variables Level JBUSP VU-MAP
Sent if TRAP
Filter enabled
1 upsTrapOnBattery Critical S05 A019
2 upsTrapTestCompleted Not managed
3 upsTrapAlarmEntryAdded Warning upsWellKnownAlarms OID
4 upsTrapAlarmEntryRemoved Information upsWellKnownAlarms OID
TRAP send to
Remote View
Pro monitoring
SW
5 upsTrapImminentStop Critical A31 A000
6 upsTrapOverload Warning A02 A001
7 upsTrapRedundancyLost Warning A43 A006
8 upsTrapBatteryCircuitOpen Critical A59 A016
9 upsTrapBatteryDischarged Critical S16 A017
10 upsTrapBatteryLow Critical S15 A018
11 upsTrapBatteryAlarm Warning A01 A027
12 upsTrapUpsCriticalAlarm Critical A52|A54|A62 A032|A040|A048
13 upsTrapLoadOFF Critical !S03&!S04 S004
14 upsTrapCommunicationLost Critical NET VISION event
15 upsTrapOnBatteryPower Warning S05 A019
16 upsTrapBatteryTestfailed Warning S14 A022
17 upsTrapTemperatureAlarm Warning A07 A020
18 upsTrapOnBypass Warning S04&!S06 S002
19 upsTrapUpsPreventiveAlarm Warning A00 A015
20 upsTrapShutdownWarning Warning
Shutdown agent
21 upsTrapShutdownrequest Warning
22 upsTrapUpsNormal Information S03 S000|S001
23 upsTrapPowerRestored Information S00 S048
24 upsTrapAlarmCancelled Information !A15 !A015
25 upsTrapComEstablished Information
Shutdown agent
26 upsTrapShutdwonCancelled Information
27 upsTrapAgentRestarting Information NET VISION event
28 upsTrapEmdTempLow Critical
EMD events
29 upsTrapEmdTempNotLow Information
30 upsTrapEmdTempHigh Critical
31 upsTrapEmdTempNotHigh Information
32 upsTrapEmdHumidityLow Critical
33 upsTrapEmdHumidityNotLow Information
34 upsTrapEmdHumidityHigh Critical
35 upsTrapEmdHumidityNotHigh Information
36 upsTrapEmdFirstInputActive Critical
37 upsTrapEmdFirstInputRestored Information
38 upsTrapEmdSecondInputActive Critical
39 upsTrapEmdSecondInputRestored Information
40 TRAP TEST Information Manual test
TRAP1 to TRAP4 are managed as dened by RFC1628.
TRAP1: sent every minute with remaining backup time and running time on battery as parameters.
TRAP3: sent every time a new alarm is added to the list.
The alarm index sent as parameters follows the well-known alarm index OID.
TRAP4: sent every time when an alarm is removed from alarm list. The alarm index is the same
as sent with TRAP3.
