List of status managed by the UPS. This table is accessible on MODBUS TCP by requesting 8
words to address 0x0030.
Reading the 4 rst words of status table are enough to monitor single UPS, as the next words
are linked to parallel system data.
Address level
Acronym
Description Address level
Acronym
Description
0x0030
I S000 Load protected by Inverter
0x0034
S064
Card in Slot 1 present
S001 Load supplied in Normal mode S065
Card in Slot 2 present
W S002 Load supplied by automatic Bypass S066
Card in Slot 3 pres-
ent
W S003
Load supplied by Maintenance Bypass
S067
Card in Slot 4 pres-
ent
C S004 Load OFF S068
Card in Slot 5 pres-
ent
S005 S069
Card in Slot 6 pres-
ent
I S006 UPS in eco mode S070
I S007 UPS in energy saver S071
S008 Burn-in mode S072 Programmable S072
W S009 In Service mode S073 Programmable S073
S010 Line-interactive mode S074 Programmable S074
I S011 Operating S075 Programmable S075
I S012 Available S076 Programmable S076
W S013 on Standby S077 Programmable S077
I S014 Unit isolated S078 Programmable S078
W S015 Maintenance Alert S079 Programmable S079
0x0031
S016 Output Breaker closed
0x0035
S080 Programmable S080
S017 Maintenance Bypass closed S081 Programmable S081
S018 External Maintenance Bypass closed S082 Programmable S082
S019 External Output Breaker closed S083 Programmable S083
S020 Single phase Input supply S084 Programmable S084
S021 Rectier Input Breaker S085 Programmable S085
S022 Bypass Input Breaker S086 Programmable S086
I S023 Gen set ON S087 Programmable S087
S024 Busbar 1 closed S088 Programmable S088
S025 Busbar 2 closed S089 Programmable S089
I S026 Automatic Start in progress S090 Programmable S090
W S027
Maintenance Bypass proc. in progress
S091 Programmable S091
W S028 UPS OFF procedure in progress S092 Programmable S092
S029 S093 Programmable S093
I S030 Auto-test Procedure in progress S094 Programmable S094
I S031 Alarm Acknowledgement requested S095 Programmable S095
