MODBUS TCP PROTOCOL
NET VISION follows IDA frame format.
MODBUS write functions 0x06 and 0x10 are not allowed.
FOR JBUSP UPS (NETYS / ITYS / MODULYS / MASTERYS MC – BC – GP – IP+ / DELPHYS MP – MX – BC – GP – XTEND)
DATA Address WORDS ACCESS TYPE ACRONYM
STATUS 0x1020 4 READ bit S00-S63
ALARMS 0x1040 4 READ bit A00-A63
MEASUREMENTS 0x1060 48 READ word M00-M47
IDENTIFIERS 0x1000 12 READ Values / ASCII I00_I11
CONFIGURATION 0x10E0 16 READ Values T00-T15
Please refer to Appendix JBUSP UPS CROSS-REF TABLE
FOR VU-MAP UPS ( ITYS-PRO / MODULYS GP 2.0 and all new UPS ranges)
DATA Address WORDS ACCESS TYPE ACRONYM
STATUS 0x0030 6+2(*) READ bit S000-S127
ALARMS 0x0038 6+2(*) READ bit A000-A127
MEASUREMENTS 0x0040 80 READ word M000 – M079
CONFIGURATIONS 0x0001 15 READ word T001 – T015
SERIAL NUMBER 0x0010 10 READ ASCII R000
UPS REFERENCE 0x001A 10 READ ASCII R001
(*) 2 additional words for units status and alarms synthesis for parallel systems UPS
Please refer to Appendix VU-MAP UPS CROSS-REF TABLE
