appendix: Jbusp ups Cross-ref table: netys / itys / masterys / delphys
List of status managed by UPS. This table is accessible on MODBUS TCP by requesting 4
words to address 0x1020.
LEVEL
NETYS PR/RT
ITYS
MASTERYS BC/
GP
DELPHYS MP/
MX
DELPHYS BC/
GP
S00 I Rectier Input supply present X X X X
S01 I Inverter ON X X X X
S02 I Rectier ON X X X X
S03 I Load protected by inverter X X X X
S04 W Load on automatic bypass X X X X
S05 W on battery / Battery discharging X X X X
S06 Remote controls disabled X X X
S07 Eco-mode ON X X X X
S08 W Stand-by mode X X
S09 Buzzer on X X X X
S10 I Battery test in progress X X X X
S11 I Battery test programmed X X X
S12 I Battery test in stand-by X X X
S13 I Battery test supported X X X X
S14 W Battery test failed X X X X
S15 C Battery near end of backup time X X X X
S16 C Battery discharged X X X X
S17 I Battery OK X X X X
S18
S19
S20
S21
S22
S23 Inverter synchro with mains X X X X
S24 Boost on X X
S25
S26 I Bypass input supply present X X X X
S27 I Battery charging X X X X
S28 Bypass input fr. out of tolerance X X X X
S29 Stand-by schedule
S30 UPS on parallel system For parallel For parallel For parallel
S31 Battery extension X
S32 Unit 1 present
If parallel system
according to
number of units
If parallel system
according to
number of units
If parallel system
according to
number of units
S33 Unit 2 present
S34 Unit 3 present
S35 Unit 4 present
S36 Unit 5 present
S37 Unit 6 present
S38 External Input 1 X X X
S39 External Input 2 X X X
S40 External Input 3 X X X
S41 External Input 4 X X X
S42 Controls permission table managed X X X X
S43 power share If present
S44
S45
S46 I Operating on Gen Set If present If present If present
S47 
S48 W Maintenance mode active X X X
S49 W End of the rst maintenance period X X X
…
S63

For more information please refer to MODBUS User manual according to the UPS range.
