List of alarms managed by the UPS. This table is accessible on MODBUS TCP by requesting 4
words to address 0x1040.
LEVEL NETYS/ITYS
MASTERYS
BC/GP
DELPHYS MP/
MX
DELPHYS GP
A00 W General Alarm X X X X
A01 W Battery failure X X X X
A02 W UPS overload X X X X
A03 Output voltage out of tolerance X
A04 Control failure X X
A05 W
Rec. input supply out of tolerance X X X
A06 W
Bypass input supply out of tolerance X X X X
A07 W Over temperature alarm X X X X
A08 W Maintenance bypass closed X X X
A09
A10 W Battery charger fault X X
A11
A12
A13 Pre-charge out of tolerance X
A14 BOOST too low X
A15 BOOST too high X
A16 VDC too high X X
A17 Improper condition of use X X
A18 Inverter stopped for overload X X X
A19 W Microprocessor control system X
A20 W data map corrupted X
A21
PLL fault (sources synchronization) X X
A22 Rectier input supply fault X X X X
A23 W Rectier preventive alarm X X X
A24
A25 W Inverter preventive alarm X X X
A26 W Charger general alarm X X X
A27 Output Voltage over limit X
A28
A29 W Bypass preventive alarm X X
A30 UPS stopped for overload X X
A31 C Imminent STOP X X X X
A32 W Unit 1 general alarm
If parallel sys-
tem according
to number of
units
If parallel sys-
tem according
to number of
units
If parallel sys-
tem according
to number of
units
A33 W Unit 2 general alarm
A34 W Unit 3 general alarm
A35 W Unit 4 general alarm
A36 W Unit 5 general alarm
A37 W Unit 6 general alarm
A38 W External alarm 1 X X X
A39 External alarm 2 X
