List of measurements managed by UPS. This table is accessible on MODBUS TCP by request-
ing 48 words to address 0x1060.
address CODE DESCRIPTION units format
NETYS/
ITYS
MAS-
TERYS
DELPHYS
MP/MX
DELPHYS
BC/GP
0x1060 M00 Load rate phase1 % ### X X X X
0x1061 M01 Load rate phase 2 % X X X
0x1062 M02 Load rate phase 3 % X X X
0x1063 M03 UPS load rate % ### X X X X
0x1064 M04 Battery Capacity % ### X X X X
0x1065 M05 Battery Capacity Ah*10 ###.# X X X
0x1066 M06
Input bypass voltage phase 1 V ### X X X X
0x1067 M07
Input bypass voltage phase 2 V X X X
0x1068 M08
Input bypass voltage phase 3 V X X X
0x1069 M09 Output voltage phase 1 V ### X X X X
0x106A M10 Output voltage phase 2 V X X X
0x106B M11 Output voltage phase 3 V X X X
0x106C M12 Input current L1 A X -1 -1
0x106D M13 Input current L2 A X -1 -1
0x106E M14 Input current L3 A X -1 -1
0x106F M15 Output current phase 1 A*10 ###.# X X X X
0x1070 M16 Output current phase 2 A*10 X X X
0x1071 M17 Output current phase 3 A*10 X X X
0x1072 M18 Input bypass frequency Hz*10 ##.# X X X X
0x1073 M19 Output frequency Hz*10 ##.# X X X X
0x1074 M20 Battery voltage (+) V*10 ###.# X X X X
0x1075 M21 Battery voltage (-) V*10 ###.# -1 X -1 -1
0x1076 M22 Ambient Temperature °C ## X X X X
0x1077 M23 Remaining backup time Minutes #### X X X X
0x1078 M24 Battery current A*10 ±###.# -1 X X X
0x1079 M25
0x107A M26
0x107B M27
0x107C M28
0x107D M29
0x107E M30
0x107F M31
0x1080 M32
0x1081 M33
Rectier input voltage phase 1 V ### X X X X
0x1082 M34
Rectier input voltage phase 2 V X X X
0x1083 M35
Rectier input voltage phase 3 V X X X
0x1084 M36 UPS output power kW*10 X X -1
0x1085 M37 Output power phase 1 kVA*10 ###.# X X X
0x1086 M38 Output power phase 2 kVA*10 X X X
0x1087 M39 Output power phase 3 kVA*10 X X X
