77
GB
NET
-VISION 7 - SOCOMEC
0x1088
M40
Input power L1
X
X
X
0x1089
M41
Input power L2
X
X
X
0x108A
M42
Input power L3
X
X
X
0x108B
M43
Rec input Fr
Hz*10
##.#
X
-1
-1
0x108C
M44
0x108D
M45
0x108E
M46
0x108F
M47
V
alue -1 means that the measurement is not managed by the UPS. and not displayed by NET VISION.
76
78
Table of Contents
Default Chapter
2
Table of Contents
2
1 Electronic Emission Notice
5
Federal Communications Commission (Fcc)
5
2 Safety Information
5
For Net Vision Card
5
For Net Vision Box
5
3 General Description
6
Net Vision Presentation
6
Socomec Ups Compatibility
6
Net Vision 7 Features
7
4 Requirements
8
Web Browser
8
NET VISION Explorer
8
5 Net Vision Installation
8
6 Ups Serial Link Settings
8
7 Net Vision 7 Boot Sequence
9
Emd Lights Sequence
9
Modbus Polling
9
Ups Data Base
10
Ups Architecture
10
8 NET VISION Explorer PRESENTATION
11
IP SETTINGS (Only for NV 7)
11
Browse
11
Fw Upgrade
12
NET VISION SETTINGS FILE DOWNLOAD (Only for NV 7)
12
Batch Operation
12
Supgrade.exe Tool
12
9 Ip Address Configuration
13
Preparing Net Vision
13
Default Ip Address
13
Net Vision Access
13
Ip Settings Using Network if Dhcp Not Present
13
IP SETTINGS USING a TERMINAL and RS232 CONNECTION for NET VISION 5 and
13
IP SETTINGS USING a TERMINAL and USB for NET VISION 7
13
10 Net Vision 6 Functions
14
11 Reset Net Vision with Factory Settings
14
12 Net Vision 7 User Interface
15
Net Vision Home Page
15
Net Vision Menu
16
Ups Architecture Tree-View
19
Ups Synoptic
19
User Login
20
13 Ups Monitoring
21
Unit Synoptic
21
System Synoptic
26
Alarm Table
27
14 Ups Dashboard
28
15 Real Time Graph
29
16 Client Table
29
17 Ups Management
30
Ups Control
30
Battery Test
31
Battery Test Schedule
31
Eco Mode SCHEDULE
32
Weekly Shutdown Schedule
32
Special Day Shutdown Schedule
32
Power Share
33
Shutdown Management
34
18 Emd Device Management
37
19 Net Vision Management
38
DATE and TIME
38
Net Vision Configuration
39
Net Vision Control
40
Multi-User Table
41
Remote View Pro Configuration
41
REMOTE VIEW PRO Server Configuration
42
SNMP V3 USM TABLE CONFIGURATION
43
Snmp Trap Receivers Configuration
43
Email Notification
45
Authentication Configuration
46
Wol Targets
47
Modbus Tcp Configuration
47
Syslog Setup
48
Ddns Setup
48
Firewall Setup
49
Upnp PROTOCOL
49
20 External LINK SETUP
50
21 History Log
51
Ups Extended History Log
53
Ups Events Log
55
Net Vision Events Log
56
Clear & Save Log Data
58
Led Definition
82
Technical Specification
82
