Introducing the SolarEdge Power Harvesting System
SolarEdge Installation Guide – MAN-01-00002-1.6
14
For installing the communication option, you may also need the following:
For Ethernet: RJ45 connectors
For RS485: Four- or six-wire twisted pair telephone cable
An inverter has either RJ45/RJ11 connectors or block terminal connectors for
communication. To install an inverter with RJ45/RJ11 connectors, you also
require the following:
For Ethernet:
• CAT5 twisted pair Ethernet cable
• RJ45 crimping tool
For RS485:
• RJ11 six-pin connector (also known as RJ25)
• RJ11 crimping tool
