SolarEdge SE3000US - PB250-AOB and PB350-AOB

Technical Specifications
SolarEdge Installation Guide – MAN-01-00002-1.6
113
OP250-LV OP300-MV/
OP400-MV
Installation Specifications
Dimensions (W x L x H) 120 x 130 x3 7 / 4.72 x 5.11 x
1.45
mm /
in
Weight 450 / 1.0 g / lb
Maximum Installation Height
2000m
Output PV Wire 0.95 m / 3 ft length ; 6 mm
2
;
MC4
Input Connector MC4 / MC3 / Tyco / H+S /
Amphenol – H4
Operating Temperature Range -40 – +65 / -40 – +150 ˚C / ˚F
Protection Rating IP65 / NEMA 4
Relative Humidity
0 - 100
%
PB250-AOB and PB350-AOB
Input
Rated Input DC Power
250
W
Absolute Maximum Input Voltage 60 (*) Vdc
MPPT Operating Range 5 – 60 Vdc
Maximum Input Current 10 Adc
Reverse-Polarity Protection
Yes
Maximum Efficiency
98.6
%
European Weighted Efficiency
97.8
%
CEC Weighted Efficiency 97.7 %
Inductive Lightning Protection 1 / 3 m / ft
Nighttime Power Consumption 0 W
