Commissioning the Installation
SolarEdge Installation Guide – MAN-01-00002-1.6
63
If the inverter is properly connected to the internet, as described in the Step 3,
Verifying Proper Operation section on page 60, then the S_OK appears in the
inverter’s LCD screen.
Providing Installation Information
Be sure to record power optimizer serial numbers during their installation, as this
information may be required later for troubleshooting
, and is necessary for proper
physical layout on the monitoring website.
iPhone Site Mapper
SolarEdge provides an iPhone Site Mapper that helps you collect information
about your installation. This application leads you through the process of
photographing the labels on each inverter and power optimizer. It then helps you
transmit this collected information to SolarEdge’s Monitoring Portal (which was
described on the previous pages). The SolarEdge iPhone Mapping Application
can be downloaded from the SolarEdge website.
Registering Installation Information on the SolarEdge
Website
Register the site using the registration form available from the following link:
http://www.solaredge.com/groups/site-registration. Fill out all required
information in the form, which includes information about your installation, as
well as details about its logical and physical mapping.
If you wish, you can also supply the following information on the form:
Logical Mapping: Showing which power optimizer is located in which
string and in which order. You can specify the logical mapping of the strings
and power optimizers, as follows:
P.Inverter_number.String_number.power optimizer_number.
For example, the third power optimizer connected to a power optimizer in the
second string in the #4 inverter in the installation is represented as P.4.2.3.
Physical Mapping: Showing a physical map (a drawing) of the location of
each power optimizer in the installation. Use the SolarEdge Physical Layout
Template available on the SolarEdge website or the site mapper mentioned
above.
The logical and physical mapping can be used in the future for debugging a
problem using the SolarEdge Monitoring Portal.
