Installing the Inverter
SolarEdge Installation Guide MAN-01-00002-1.6
32
Refer to the following table to determine the correct fuse size to use at the
connection point of the Single Phase Inverter to the grid:
Inverter Maximum Output Current
Suggested Breaker
or Fuse
208 VAC
SE3000
14.5 A
20 A
SE3800
18.5 A
25 A
SE5000
24 A
30 A
SE6000
25 A
35 A or 40 A
SE7000
25 A
35 A or 40 A
240 VAC
SE3000
12.5 A
20 A
SE3800
16 A
20 A
SE5000
21 A
30 A
SE6000
25 A
35 A or 40 A
SE7000
25 A
35 A or 40 A
277 VAC
SE3000
---
---
SE3800
---
---
SE5000
18.5 A
25 A
SE6000
22 A
30 A
SE7000
25 A
35 A or 40 A
WARNING!
For more wiring information, you may refer to the Application Note called
SolarEdge Recommended AC Wiring,
which can be accessed from the SolarEdge
website.
Pour plus d'informations
de câblage, vous pouvez vous référer à la Note
d'application
appelée SolarEdge Recommended AC Wiring, qui peut être
consultée sur le site SolarEdge.
