SolarEdge SE3000US User Manual

Commissioning the Installation
SolarEdge Installation Guide – MAN-01-00002-1.6
58
NOTE:
If the LCD panel shows 0 V:

Verify that the PV modules are are not shaded or otherwise obstructed.

Check for proper power optimizer, string and DC input connection.
 Verify the correct polarity of the DC input connection.
8 Verify that Pac [w] on the LCD panel specifies 0 as the AC output power, in
Watts. This is because the inverter is still off.
WARNING
!
Verify that the ON/OFF indicator on the LCD panel, described above, reads
OFF.
Vérifiez que l'indicateur ON/OFF sur le panneau d'affichage LCD décrit ci
-
dessus
lit OFF.
Step 2, Pairing Power Optimizers to the
Inverter
After all connections are made, all the power optimizers must be logically paired
to their inverter before they can start working with it. This step describes how to
pair power optimizers to the inverter, meaning to assign each inverter to the
power optimizers from which it will produce power.
NOTE:
The power optimizer does not start producing power until it is paired with an inverter.
► To pair the power optimizers to the inverter:
1 Turn the ON/OFF switch at the bottom of the inverter to off. Press and hold
down the inverter’s LCD Light button for about 10 seconds. The following
screen is displayed:
K
e
e
p
h
o
l
d
i
n
g
b
u
t
t
o
n
f
o
r
p
a
i
r
i
n
g
,
r
e
l
e
a
s
e
t
o
e
n
t
e
r
m
e
n
u
.
.
.
R
e
m
a
i
n
i
n
g
:
3
s
e
c
