Setting Up Communication
SolarEdge Installation Guide – MAN-01-00002-1.6
68
Ethernet and RS485 are connected to a connector inside the inverter. An inverter
communication board has either RJ45/RJ11 connectors or block terminal
connectors for communication.
The following shows the location of the RJ45/RJ11 communication connectors:
Figure 34: Ethernet and RS485 – RJ45/RJ11 Connectors
The following shows the location of the block terminal communication
connectors:
Figure 35: Block Terminal Connectors
RS485-1 (B, A G from left to right)
