9-1
BVM-D32E1WA/D32E1WE/D32E1WU
Section 9
Electrical Parts List
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
* A-1136-107-A BC COMPL
***********
* 1-526-652-21 SOCKET, IC (DP) 8P
1-540-222-11 SOCKET, IC (PCC PACKAGE) 84P
1-550-104-11 HOLDER, BATTERY
1-678-590-11 PWB, BC
3-648-057-00 NUT (ISO-4), U
* 4-050-794-03 INSULATOR
* 4-050-804-01 SCREW, PANEL STOPPER
7-432-114-11 SCREW LOCK
7-682-647-09 SCREW +PS 3X6
7-685-872-09 SCREW +BVTT 3X8 (S)
<CAPACITOR>
C1 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C2 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C4 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C5 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C7 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C12 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C13 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C14 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C31 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C32 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C33 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C34 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C35 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C36 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C37 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C39 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C41 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C42 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C43 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C44 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C45 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C46 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C47 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C51 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C101 1-109-982-11 CERAMIC CHIP 1µF 10% 10V
C102 1-164-346-11 CERAMIC CHIP 1µF 16V
C103 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C104 1-163-275-11 CERAMIC CHIP 0.001µF 5% 50V
C112 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C154 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C155 1-164-182-11 CERAMIC CHIP 0.0033µF 10% 50V
C156 1-164-344-11 CERAMIC CHIP 0.068µF 10% 25V
C157 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C158 1-128-526-11 ELECT 100µF 20% 10V
C159 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C232 1-126-396-11 ELECT CHIP 47µF 20% 16V
C246 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C247 1-107-888-11 ELECT 47µF 20% 25V
C250 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C251 1-107-888-11 ELECT 47µF 20% 25V
C252 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C253 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C281 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C282 1-104-652-11 ELECT 470µF 20% 10V
C283 1-104-652-11 ELECT 470µF 20% 10V
C300 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C301 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C302 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C303 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C304 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C305 1-163-145-00 CERAMIC CHIP 0.0015µF 5% 50V
C306 1-163-145-00 CERAMIC CHIP 0.0015µF 5% 50V
C313 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C314 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C351 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C352 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C374 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C375 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C376 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C377 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C378 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C379 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C380 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C381 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C382 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C405 1-107-909-11 ELECT 47µF 20% 16V
C406 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C407 1-164-690-91 CERAMIC CHIP 0.0022µF 5% 50V
C551 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C552 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C553 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C554 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C555 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C556 1-163-031-11 CERAMIC CHIP 0.01µF 50V
C557 1-163-031-11 CERAMIC CHIP 0.01µF 50V
BC
NOTE :
• Items marked “ * ” are not stocked since they are seldom required
for routine service. Some delay should be anticipated when
ordering these items.
• Due to standardization, replacements in the parts list may be
different from the parts specified in the diagrams or the components
used on the set.
RESISTORS
• All resistors are in ohms.
• F: nonflammable
• METAL: Metal-film resistor
• METAL OXIDE: Metal oxide-film resistor
The components identified marked ! are
critical for safety.
Replace only with the part number specified.
Les composants identifiés par la marque !
sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
To Next Page
