BVM-D32E1WA/D32E1WE/D32E1WU
Table of Contents
1. Operating Instructions..................................................... 1-1
2. Service Informations
2-1. Circuit Boards Location ..............................................................................2-1
2-2-1. Cover Removal...........................................................................2-2
2-2-2. PA Board Open .......................................................................... 2-2
2-2-3. FBT Block Assy Removal .........................................................2-3
2-2-4. BUF2, E and G Boards Removal and Check .............................2-4
2-2-5. BC and BK Boards Removal and Check ...................................2-5
2-2-6. TA1 and TB Board Removal .....................................................2-6
2-2-7. DC and HD Boards Removal .....................................................2-7
2-2-8. YA, YB and YC Boards Removal .............................................2-7
2-2-9. Picture Tube Removal ................................................................2-8
3. Set-Up Adjustment
3-1. Set-Up Adjustment When CRT is Replaced ...............................................3-1
[Focus adjustment] ......................................................................................3-2
[Landing Adjustment] .................................................................................3-4
[H Blanking Adjustment] ............................................................................3-5
[Linearity Adjustment]................................................................................3-8
[Convergence Adjustment] .......................................................................3-10
[Static Convergence Adjustment] .............................................................3-11
[Convergence Adjustment] .......................................................................3-11
[G2 Adjustment]........................................................................................3-12
[White Balance Adjustment] .....................................................................3-13
4. Safety Related Adjustments
+B (135V) Voltage Adjustments ................................................................4-1
High Voltage Regulator Check/Adjustment ...............................................4-1
High Voltage Hold-Down Check/Adjustment ............................................4-1
Beam Current Protector Check ...................................................................4-2
