Sony BVM-D32E1WA - DC and HD Boards Removal; YA, YB and YC Boards Removal

2-7
BVM-D32E1WA/D32E1WE/D32E1WU
2-2-7. DC and HD Boards Removal
2-2-8. YA, YB and YC Boards Removal
2 HD board
1 Two screws
4 Open the DC board in the
direction of arrow.
3 Two PWB holders
CN102
8 Two screws
(+BVTT3 x 6)
2 Two screws
(+B4 x 10)
9 YC board
5 YA board
7 YB board
4 Two claws
3 Bezel assy
1 Two screws
(+B4 x 10)
6 Screw
(+BVTT3 x 6)
CN301
CN101
CN201
