62
Chapter 3 Appendix
Effective picture size with 4:3 aspect
ratio:
361.6 × 271.2 mm (14
1
/
4
× 10
3
/
4
inches)
(w/h)
452.0 mm (17
7
/
8
inches) (diagonal size)
CRT protection: EHT (extremely high
tension) protection type
Warm-up time: approx. 30 minutes
Anode voltage: 27 kV with no beam
current
Nominal chromaticity coordinates:
SMPTE C phosphor (BVM-D24E1WU)
EBU phosphor (BVM-D24E1WE/
D24E1WA)
Error: ± 0.005 or less
BVM-D32E1WU/D32E1WE/D32E1WA
Super fine pitch Trinitron, flat surface,
16:9 aspect ratio
Aperture grille pitch: 0.32-0.36 mm
90 degree deflection, 29.1 mm diameter
in-line gun
Effective picture size with 16:9 aspect
ratio:
655.2 × 368.5 mm (25
7
/
8
× 14
5
/
8
inches)
(w/h)
751.7 mm (29
5
/
8
inches) (diagonal size)
Effective picture size with 4:3 aspect
ratio:
491.3 × 368.5 mm (19
3
/
8
× 14
5
/
8
inches)
(w/h)
614.1 mm (24
1
/
4
inches) (diagonal size)
CRT protection: EHT (extremely high
tension) protection type
Warm-up time: approx. 30 minutes
Anode voltage: 27 kV with no beam
current
Specifications
General
System 15.625 kHz – 45 kHz (For details, see
“Available Signal Formats” on page 65.)
CRT
BVM-D20F1U/D20F1E/D20F1A
Super fine pitch Trinitron, 4:3 aspect ratio
Aperture grille pitch: 0.3 mm
90 degree deflection, 30.6 mm diameter
in-line gun
Effective picture size with 16:9 aspect
ratio:
386 × 218 mm (15
1
/
4
× 8
5
/
8
inches) (w/h)
443 mm (17
1
/
2
inches) (diagonal size)
Effective picture size with 4:3 aspect
ratio:
386 × 291 mm (15
1
/
4
× 11
1
/
2
inches)
(w/h)
482 mm (19 inches) (diagonal size)
CRT protection: EHT (extremely high
tension) protection type
Warm-up time: approx. 30 minutes
Anode voltage: 27 kV with no beam
current
Nominal chromaticity coordinates:
SMPTE C phosphor (BVM-D20F1U)
EBU phosphor (BVM-D20F1E/D20F1A)
Error: ± 0.005 or less
BVM-D24E1WU/D24E1WE/D24E1WA
Super fine pitch Trinitron, flat surface,
16:9 aspect ratio
Aperture grille pitch: 0.25-0.28 mm
90 degree deflection, 29.1 mm diameter
in-line gun
Effective picture size with 16:9 aspect
ratio:
482.1 × 271.2 mm (19 × 10
3
/
4
inches)
(w/h)
553.1 mm (21
7
/
8
inches) (diagonal size)
xy
R 0.630 0.340
G 0.310 0.595
B 0.155 0.070
xy
R 0.640 0.330
G 0.290 0.600
B 0.150 0.060
xy
R 0.630 0.340
G 0.310 0.595
B 0.155 0.070
xy
R 0.640 0.330
G 0.290 0.600
B 0.150 0.060
63
Chapter 3 Appendix
Chapter 3 Appendix
Nominal chromaticity coordinates:
SMPTE C phosphor (BVM-D32E1WU)
EBU phosphor (BVM-D32E1WE/
D32E1WA)
Error: ± 0.005 or less
Mass BVM-D20F1U/D20F1E/D20F1A:
approx. 38 kg (83 lb 12 oz)
BVM-D24E1WU/D24E1WE/
D24E1WA: approx. 51 kg (112 lb 7 oz)
BVM-D32E1WU/D32E1WE/
D32E1WA: approx. 94 kg (427 lb 11
oz)
Power consumption
BVM-D20F1U/D20F1E/D20F1A:
155 W
When an optional adaptor is installed:
210 W
BVM-D24E1WU/D24E1WE/
D24E1WA: 150 W
When an optional adaptor is installed:
205 W
BVM-D32E1WU/D32E1WE/
D32E1WA: 180 W
When an optional adaptor is installed:
235 W
Power requirements
BVM-D20F1U/D20F1E/D20F1A: 100
to 240 V AC, 2.3 to 1.0 A, 50/60 Hz
BVM-D24E1WU/D24E1WE/
D24E1WA: 100 to 240 V AC, 2.1 to
0.9 A, 50/60 Hz
BVM-D32E1WU/D32E1WE/
D32E1WA: 100 to 240 V AC, 2.4 to
1.0 A, 50/60 Hz
Peak inrush current
(1) Power ON, current probe method:
47 A (240 V)
(2) Hot switching inrush current,
measured in accordance with
European standard EN55103-1
18 A (230 V)
xy
R 0.630 0.340
G 0.310 0.595
B 0.155 0.070
xy
R 0.640 0.330
G 0.290 0.600
B 0.150 0.060
Input/output connectors
Video input BNC type × 3 (with loop-through
outputs)
G/B/R: Composite 1.0 Vp-p or non-
composite 0.7 Vp-p
Y: Composite 1.0 Vp-p or non-composite
0.7 Vp-p
P
B
/P
R
: Non-composite 0.7 Vp-p
Sync: ±0.3 V±6 dB, positive/negative, tri-
level sync, or 0.3 V±6 dB negative sync
Sync input BNC type × 1 (with loop-through output)
0.3 to 8 Vp-p, positive/negative, tri-level
sync signal input, or 0.3 to 8 Vp-p,
negative sync signal input
Return loss More than 40 dB (10 MHz, with
75-ohm termination)
Remote control
OPTION: Mini-DIN 8-pin × 1
CONTROL UNIT: D-sub 9-pin × 1
REMOTE 1: D-sub 9-pin × 1 (with loop-
through output), RS-485 serial
interface
REMOTE 2: D-sub 9-pin × 1
ISR: D-sub 9-pin × 1
Video signal
Differential gain
BVM-D20F1U/D20F1E/D20F1A/
D24E1WU/D24E1WE/D24E1WA:
Less than 5% (for luminance from 0 to
100 cd/m
2
)
BVM-D32E1WU/D32E1WE/
D32E1WA: Less than 5% (for luminance
from 0 to 70 cd/m
2
)
Differential phase
BVM-D20F1U/D20F1E/D20F1A/
D24E1WU/D24E1WE/D24E1WA:
Less than 5° (for luminance from 0 to
100 cd/m
2
)
BVM-D32E1WU/D32E1WE/
D32E1WA: Less than 5° (for luminance
from 0 to 70 cd/m
2
)
Frequency response
50 Hz to 30 MHz, +1 dB/ –3 dB
DC restoration
Back porch type
Black level fluctuation: less than 1% for
10 % to 90% APL input signal variation
To Next Page
