3-3
BVM-D32E1WA/D32E1WE/D32E1WU
NT/American system
MODE 1 1080/60i (33 kHz) 16:9N
MODE 2 1125 16:9U
MODE 3 1035/60i (33 kHz) 16:9N
MODE 4 1125 16:9U
MODE 5 720/60p (45 kHz) 16:9N
MODE 6 16:9U
MODE 7 480/60p (31 kHz) 16:9N
MODE 8 525 16:9U
MODE 9 4:3N
MODE 10 4:3U
MODE 11 480/60p (15 kHz) 16:9N
MODE 12 525 16:9U
MODE 13 4:3N
MODE 14 4:3U
MODE 15 1080/48i (27 kHz) 16:9N
MODE 16 1125 16:9U
DTV format screen mode table
PAL/European system
MODE 17 1080/50i (28 kHz) 16:9N
MODE 18 1125 16:9U
MODE 19 720/50p (37 kHz) 16:9N
MODE 20 16:9U
MODE 21 575/50p (31 kHz) 16:9N
MODE 22 625 16:9U
MODE 23 4:3N
MODE 24 4:3U
MODE 25 575/50i (15 kHz) 16:9N
MODE 26 625 16:9U
MODE 27 4:3N
MODE 28 4:3U
MODE 29 1080/50i (31 kHz) 16:9N
MODE 30 1250 16:9U
MODE 31 1152/50i (31 kHz) 16:9N
MODE 32 1120 16:9U
Table. 1
For the MODE 29 through 32, all the adjustment work is only to enter the initial value to the memory
area. → Do not make any adjustment.
