6-27
DCR-PC350/PC350E
8. Flange Back Check
8-1. Flange Back Check
(Using Flange Back Adjustment Jig)
Subject Flange back adjustment jig
(Luminance : approx. 200 lux)
Measurement Point Check operation on TV monitor
Measuring Instrument
Specified Value
Focused at the TELE end and WIDE end.
Note: The data of page: 0, address: 10 must be “00”.
Switch setting:
1) POWER....................................................... CAMERA-TAPE
2) NIGHT SHOT..................................................................OFF
Preparations:
1) Install the flange back adjustment jig so that the distance
between it and the front of the lens of the camcorder is less
than 3cm.
2) To open the IRIS, decrease the luminous intensity to the chart
of the flange back adjustment jig up to a point before noise
appear on the image. (Approx. 200 lux)
3) Check that at both the zoom TELE end and WIDE end, the
center of the chart and center of the monitor TV screen coincide.
Checking method:
Order Page
Address
Data Procedure
1 6 40 01 Set the data.
2 6 41 01 Set the data.
3 Shoot the chart with the zoom
TELE end.
4 6 2C 02 Set the data.
5 Check that the lens is focused.
6 Shoot the chart with the zoom
WIDE end.
7 Check that the lens is focused.
Processing after Completing Adjustments:
Order Page
Address
Data Procedure
1 6 2C 00 Set the data.
2 6 40 00 Set the data.
3 6 41 00 Set the data.
8-2. Flange Back Check (Using Siemens Star)
Subject Siemens star
(2.0m from the front of the lens)
(Luminance : approx. 200 lux)
Measurement Point Check operation on TV monitor
Measuring Instrument
Specified Value Focused at the TELE end and WIDE
end.
Note1: The data of page: 0, address: 10 must be “00”.
Note2: When the auto focus is ON, the lens can be checked if it is focused
or not by observing the data on the page 1 of the adjustment remote
commander.
1) Select page: 0, address: 03, and set data: 0F.
2) Page 1 shows the state of the focus.
1 : 00 : XX
Odd: Focused
Even: Unfocused
Switch setting:
1) POWER....................................................... CAMERA-TAPE
2) NIGHT SHOT ..................................................................OFF
Preparations:
1) Place the Siemens star 2.0m from the front of the lens.
2) To open the IRIS, decrease the luminous intensity to the
Siemens star up to a point before noise appear on the image.
(Approx. 200 lux)
Checking method:
Order Page
Address
Data Procedure
1 6 40 01 Set the data.
2 6 41 01 Set the data.
3 Shoot the chart with the zoom
TELE end.
4 Turn on the auto focus.
5 Check that the lens is focused.
(Note2).
6 6 21 10 Set the data.
7 Shoot the chart with the zoom
WIDE end.
8 Check that the lens is focused.
Processing after Completing Adjustments:
Order Page
Address
Data Procedure
1 6 21 00 Set the data.
2 6 40 00 Set the data.
3 6 41 00 Set the data.
4 0 03 00 Set the data.
To Next Page
