6-66
DCR-PC350/PC350E
13. Record of Self-diagnosis check
Page 7 Address B0 to C6
Note1: This data will be kept even if the lithium battery (MS-234 board
BT800) is removed.
Note2: The data of page: 0, address: 10 must be “00”.
Address Self-diagnosis code
B0 “Repaired by” code (Occurred 1st time) *1
B1 “Block function” code (Occurred 1st time)
B2 “Detailed” code (Occurred 1st time)
B4 “Repaired by” code (Occurred 2nd time) *1
B5 “Block function” code (Occurred 2nd time)
B6 “Detailed” code (Occurred 2nd time)
B8 “Repaired by” code (Occurred 3rd time) *1
B9 “Block function” code (Occurred 3rd time)
BA “Detailed” code (Occurred 3rd time)
BC “Repaired by” code (Occurred 4th time) *1
BD “Block function” code (Occurred 4th time)
BE “Detailed” code (Occurred 4th time)
C0 “Repaired by” code (Occurred 5th time) *1
C1 “Block function” code (Occurred 5th time)
C2 “Detailed” code (Occurred 5th time)
C4 “Repaired by” code (Occurred the last time) *1
C5 “Block function” code (Occurred the last time)
C6 “Detailed” code (Occurred the last time)
*1: “01” t “C”, “03” t “E”
Using method:
1) The past self-diagnosis codes are displayed at addresses: B0 to C6. Refer to “SELF-DIAGNOSIS CODE TABLE” for detail of the self-
diagnosis code.
Initializing method:
1) Select page: 7, address: 01, and set data: C0.
2) Select page: 7, address: 00, set data: 01 and press the PAUSE button.
3) Check that the data of page: 7, address: B0 to C7 are “00”.
4) Select page: 7, address: 00, and set data: 00.
5) Select page: 7, address: 01, and set data: 00.
Note3: When the flash error code (E: 91:
**
) is displayed. After repair, clear the error flag in the following method.
1) Select page: 7, address: 01, and set data: 75.
2) Select page: 7, address: 00, set data: 01 and press the PAUSE button.
3) Check that the data of page: 7, address: 02 is “01”.
To Next Page
