Sony DCR-PC350 - White Balance Adjustment (VC-370 Board)

6-41
DCR-PC350/PC350E
2. White Balance Adjustment (VC-370 board)
Correct the white balance.
If deviated, the reproduction of the EVF screen may degenerate.
Mode CAMERA-TAPE
Subject Arbitrary
Measurement Point Check on EVF screen
Measuring Instrument
Adjustment Page C
Adjustment Address 45, 46
Specified Value The EVF screen should not be colored.
Note1: Check the white balance only when replacing the following parts.
If necessary, adjust them.
1. LCD panel
2. Light induction plate
3. IC1650
Note2: The data of page: 0, address: 10 must be “00”.
Adjusting method:
Order Page Address Data Procedure
1 0 01 01 Set the data.
2 C 45 Set the following data, and press
PAUSE button.
8E (NTSC), 8D (PAL)
3 C 46 Set the following data, and press
PAUSE button.
8C (NTSC), 8F (PAL)
4 C 46 Check that the EVF screen is not
colored. If not colored, proceed to
step 10.
5 C 45 Change the data so that the EVF
screen is not colored.
6 C 45 Press PAUSE button.
7 C 46 Change the data so that the EVF
screen is not colored.
8 C 46 Press PAUSE button.
9 C 46 If the EVF screen is colored,
repeat steps 5 to 9.
10 0 01 00 Set the data.
