DV MECHANICAL ADJUSTMENT MANUAL VII
MECHANISM DECK
Z MECHANISM
Please use this manual with the service manual of the respective models.
The capstan motor and the drum base block assy of this mechanism require very
high precision work to install them in the mechanism. Therefore, the capstan motor
and the drum base block assy are not supplied as the repair part independently.
They are supplied as MD (Z100) SUB block assy.
Ver 1.0 2003. 01
To Next Page
