6-15
DCR-PC350/PC350E
1-2-3. INITIALIZATION OF E, F, 14, 19, 1E, 1F PAGE DATA
Note: When reading or writing the E, F page data, select page: 0, address:
10, and set data: 00.
When reading or writing the 14, 19, 1E and 1F page data, select
page: 0, address: 10, and set data: 01, then select 4, 9, E or F page.
The 14, 19, 1E or 1F page can be chosen by this data setting.
After reading or writing, reset the data of page: 0, address: 10 to
“00”.
1. Initializing the E, F, 14, 19, 1E, 1F Page Data
Note1: If “Initializing the E, F, 14, 19, 1E, 1F Page Data” is performed,
all data of the E page, F page, 14 page, 19 page, 1E page and 1F
page will be initialized. (It is impossible to initialize a single page.)
Note2: If the E, F, 14, 19, 1E, 1F page data has been initialized, following
adjustments need to be performed again.
1) Modification of E, F, 14, 19, 1E, 1F page data
2) Camera system adjustments
Adjusting page E
Adjusting Address 00 to FF
Adjusting page F
Adjusting Address 10 to FF
Adjusting page 14
Adjusting Address 00 to FF
Adjusting page 19
Adjusting Address 00 to FF
Adjusting page 1E
Adjusting Address 00 to FF
Adjusting page 1F
Adjusting Address 00 to FF
Initializing Method:
Order Page
Address
Data Procedure
1 0 01 01 Set the data.
2 0 10 00 Set the data.
3 6 01 Set the following data, and press
PAUSE button.
2D: DCR-PC350 (NTSC)
2F: DCR-PC350E (PAL)
4 6 03 03 Set the data, and press PAUSE
button.
5 6 02 Check that the data changes to
“01”.
6 6 01 00 Set the data, and press PAUSE
button.
7 Perform “Modification of E, F,
14, 19, 1E, 1F Page Data”.
2. Modification of E, F, 14, 19, 1E, 1F Page Data
If the E, F, 14, 19, 1E, 1F page data has been initialized, change the
data of the “Fixed data-2” address shown in the following table by
manual input.
Modifying Method:
1) Before changing the data, select page: 0, address: 01, and set
data: 01.
2) When changing the E, F page data, select page: 0, address: 10,
and set data: 00.
3) When changing the 14, 19, 1E, 1F page data, select page: 0,
address: 10, and set data: 01.
After completing the modification of 14, 19, 1E, 1F page data,
reset the data of this address to “00”.
4) New data for changing are not shown in the tables because
they are different in destination. When changing the data, copy
the data built in the same model.
Note: If copy the data built in the different model, the camcorder may
not operate.
5) When changing the data, press the PAUSE button of the
adjustment remote commander each time when setting new
data to write the data in the non-volatile memory.
6) Check that the data of adjustment addresses is the initial value.
If not, change the data to the initial value.
Processing after Completing Modification of E, F, 14, 19, 1E,
1F Page data
Order Page
Address
Data Procedure
1 0 10 00 Set the data.
2 2 00 29 Set the data.
3 2 01 29 Set the data, and press PAUSE
button.
3. E Page Table
Note1: The data of page: 0, address: 10 must be “00”.
Note2: Fixed data-1: Initialized data. (Refer to “1. Initializing the E, F,
14, 19, 1E, 1F Page Data”.)
Fixed data-2: Modified data. (Refer to “2. Modification of E, F,
14, 19, 1E, 1F Page Data”).
Address
00 to 04
05
06 to 07
08
09
0A
0B
0C to 12
13
14 to 1A
1B
1C to 1F
20
21
22
23
24 to 30
31
32 to 5B
5C
5D
5E to 5F
60
61
62 to 65
66
67
68
69
6A to 71
72
73 to FF
Remark
Fixed data-1
Fixed data-2
Fixed data-1
Fixed data-2
(Modified data. Copy the data
built in the same model.)
Fixed data-1
Fixed data-2
Fixed data-1
Fixed data-2
Fixed data-1
Fixed data-2
(Modified data. Copy the data
built in the same model.)
Fixed data-1
Fixed data-2
Fixed data-1
Fixed data-2
Fixed data-1
Fixed data-2
Fixed data-1
Fixed data-2
(Modified data. Copy the data
built in the same model.)
Fixed data-1
Fixed data-2
Fixed data-1
Table. 6-1-10.
