Pin No. Pin Name I/O Description
E21 RGMII_TD2 O RGMII transmit data output to the ethernet transceiver
E22 EIM_EB2 I Boot mode setting terminal Fixed at “L”
E23 EIM_D22 O VBUS power on/off control signal output terminal for the USB connector “H”: power on
E24, E25 EIM_D26, EIM_D27 - Not used
F1 CSI_D3P - Not used
F2 CSI_D3M - Not used
F3 CSI_CLK0P - Not used
F4 CSI_CLK0M - Not used
F5 to F8 GND33 to GND36 - Ground terminal
F9 VDDUSB_CAP1 O Internal regulator output terminal
F10 USB_H1_DN I/O Two-way USB data (negative) with the WLAN/BT COMBO card
F11 PMIC_STBY_REQ O Not used
F12 BOOT_MODE1 I Boot mode setting terminal Fixed at “H”
F13 SD3_DAT7 - Not used
F14 SD3_DAT1 - Not used
F15 NANDF_CS0 - Not used
F16 NANDF_D2 - Not used
F17 SD4_DAT2 I/O Two-way data bus with the fl ash memory
F18 SD1_DAT3 - Not used
F19 SD2_CMD - Not used
F20 RGMII_TD1 O RGMII transmit data output to the ethernet transceiver
F21, F22 EIM_D17, EIM_D24 - Not used
F23 EIM_EB3 I Boot mode setting terminal Fixed at “L”
F24, F25 EIM_A22, EIM_A24 I Boot mode setting terminal Fixed at “L”
G1 DSI_D0P - Not used
G2 DSI_D0M - Not used
G3 GND39 - Ground terminal
G4 DSI_REXT - Not used
G5 JTAG_TDI - Not used
G6 JTAG_TDO - Not used
G7 PCIE_VPH - Power supply terminal for the PCIe interface (+2.5V)
G8 PCIE_VPTX - Power supply terminal for the PCIe interface (+1.1V)
G9 VDD_SNVS_CAP O Internal regulator output terminal
G10 GND37 - Ground terminal
G11 VDD_SNVS_IN - Power supply terminal for the SNVS Regulator (+3.3V)
G12 SATA_VPH - Power supply terminal for the SATA interface (+2.5V)
G13 SATA_VP - Power supply terminal for the SATA interface (+1.1V)
G14 NVCC_SD3 O Internal regulator output terminal
G15 NVCC_NANDF O Internal regulator output terminal
G16,
G17
NVCC_SD1,
NVCC_SD2
O Internal regulator output terminal
G18 NVCC_RGMII - Power supply terminal for the ENET interface (+1.8V)
G19 GND38 - Ground terminal
G20 EIM_D20 O Confi guration signal output to the FPGA
G21,
G22
EIM_D19, EIM_D25 - Not used
G23 EIM_D28 I Diag mode enable signal input terminal
G24,
G25
EIM_A17, EIM_A19 I Boot mode setting terminal Fixed at “L”
H1 DSI_D1P - Not used
H2 DSI_D1M - Not used
H3 DSI_CLK0M - Not used
H4 DSI_CLK0P - Not used
H5 JTAG_TCK - Not used
H6 JTAG_MOD - Not used
H7 PCIE_VP - Power supply terminal for the PCIe interface (+1.1V)
H8 GND43 - Ground terminal
H9 VDDHIGH_IN1 - Power supply terminal for the +2.5V regulator (+3.3V)
H10 VDDHIGH_CAP1 O Internal regulator output terminal (+2.5V)
H11 VDDARM23_CAP1 O Internal regulator output terminal Not used
