Sony HAP-S1 Service Manual

HAP-S1
94
Pin No. Pin Name I/O Description
AA19 GND8 - Ground terminal
AA20,
AA21
DRAM_D45,
DRAM_D57
- Not used
AA22 GND9 - Ground terminal
AA23 DRAM_D61 - Not used
AA24 DRAM_SDQS7_B - Not used
AA25 DRAM_SDQS7 - Not used
AB1 LVDS1_TX2_N - Not used
AB2 LVDS1_TX2_P - Not used
AB3 GND12 - Ground terminal
AB4 to
AB7
DRAM_D6,
DRAM_D12,
DRAM_D14,
DRAM_D16
I/O Two-way data bus with the SD-RAM
AB8 DRAM_DQM2 O Data mask (upper byte) signal output to the SD-RAM
AB9 DRAM_D18 I/O Two-way data bus with the SD-RAM
AB10 DRAM_SDQS3_B O Data strobe signal (lower byte) output to the SD-RAM
AB11 DRAM_D27 I/O Two-way data bus with the SD-RAM
AB12 DRAM_SDBA2 O Bank address signal output to the SD-RAM
AB13,
AB14
DRAM_A8,
DRAM_A1
O Address signal output to the SD-RAM
AB15 DRAM_RAS O Row address signal output to the SD-RAM
AB16 DRAM_SDWE O Write enable signal output to the SD-RAM
AB17 DRAM_SDODT1 - Not used
AB18 DRAM_DQM4 - Not used
AB19 to
AB23
DRAM_D38,
DRAM_D41,
DRAM_D42,
DRAM_D52,
DRAM_D60
- Not used
AB24 GND11 - Ground terminal
AB25 DRAM_D56 - Not used
AC1 DRAM_D4 I/O Two-way data bus with the SD-RAM
AC2 DRAM_VREF I Reference voltage input terminal
AC3 DRAM_DQM0 O Data mask (lower byte) signal output to the SD-RAM
AC4,
AC5
DRAM_D2,
DRAM_D13
I/O Two-way data bus with the SD-RAM
AC6 DRAM_DQM1 O Data mask (upper byte) signal output to the SD-RAM
AC7 to
AC9
DRAM_D15,
DRAM_D22,
DRAM_D28
I/O Two-way data bus with the SD-RAM
AC10 DRAM_SDQS3 O Data strobe signal (lower byte) output to the SD-RAM
AC11 DRAM_D31 I/O Two-way data bus with the SD-RAM
AC12 to
AC14
DRAM_A11,
DRAM_A6,
DRAM_A0
O Address signal output to the SD-RAM
AC15 DRAM_SDBA0 O Bank address signal output to the SD-RAM
AC16 DRAM_SDODT0 O On die termination signal output to the SD-RAM
AC17 DRAM_A13 O Address signal output to the SD-RAM
AC18,
AC19
DRAM_D34,
DRAM_D39
- Not used
AC20 DRAM_DQM5 - Not used
AC21 to
AC25
DRAM_D47,
DRAM_D48,
DRAM_D53,
DRAM_D51,
DRAM_D55
- Not used
AD1,
AD2
DRAM_D5,
DRAM_D0
I/O Two-way data bus with the SD-RAM
AD3 DRAM_SDQS0_B O Data strobe signal (lower byte) output to the SD-RAM
AD4 GND18 - Ground terminal
AD5 DRAM_D8 I/O Two-way data bus with the SD-RAM
AD6 DRAM_SDQS1 O Data strobe signal (upper byte) output to the SD-RAM
