Sony HCD-GT3D - Page 38

HCD-GT3D
HCD-GT3D
3838
320 ns
22 Ps
3.4 Vp-p
1 Vp-p
22 Ps
350 ns
3.4 Vp-p
3.9 Vp-p
350 ns
3.8 Vp-p
350 ns
3.8 Vp-p
22 Ps
81 ns
60 ns
3.4 Vp-p
22 Ps
3.4 Vp-p
22 Ps
3.4 Vp-p
3.3 Vp-p
4 Vp-p
37.5 ns
60 ns
359 ns
740 mVp-p
4 Vp-p
3.8 Vp-p
3.5 Vp-p
ql IC301 8 (XTALO)
200 mV/DIV, 25 ns/DIV
w; IC301 <zzx (ACLK)
1 V/DIV, 25 ns/DIV
wa IC301 <zzc (ABCK)
1 V/DIV, 100 ns/DIV
ws IC301 <zzm (ALRCK)
1 V/DIV, 10 Ps/DIV
wd IC301 <zxc (RFIP)
200 mV/DIV, 500 ns/DIV
wf IC604 1 (BCK)
1 V/DIV, 100 ns/DIV
wg IC604 3 (LRCK)
1 V/DIV, 10 Ps/DIV
wh IC604 qh (SCK)
1 V/DIV, 25 ns/DIV
wj IC606 6 (SCKI)
2 V/DIV, 50 ns/DIV
wk IC606 7 (LRCK)
1 V/DIV, 10 Ps/DIV
wl IC606 8 (BCK)
2 V/DIV, 250 ns/DIV
e; IC609 6 (SCKI)
2 V/DIV, 50 ns/DIV
ea IC609 7 (LRCK)
1 V/DIV, 10 Ps/DIV
es IC609 8 (BCK)
2 V/DIV, 250 ns/DIV
ed IC615 1 (BCK)
2 V/DIV, 250 ns/DIV
ef IC615 3 (LRCK)
1 V/DIV, 10 Ps/DIV
eg IC615 qh (SCK)
2 V/DIV, 250 ns/DIV
eh IC902 qh (X1)
50 mV/DIV, 50 ns/DIV
81 ns
3.4 Vp-p
81 ns
85 ns
3.4 Vp-p
140 mVp-p
22 Ps
3.4 Vp-p
5.75 Ps
375 Ps
3.4 Vp-p
5.75 Ps
3.4 Vp-p
350 ns
3.8 Vp-p
22 Ps
3.4 Vp-p
22 Ps
3.4 Vp-p
359 ns
3.8 Vp-p
359 ns
3.8 Vp-p
ej IC902 qj (X2)
100 mV/DIV, 50 ns/DIV
ek IC904 qk (LRCK)
1 V/DIV, 250 Ps/DIV
el IC904 ql (BCK)
1 V/DIV, 2.5 Ps/DIV
r; IC904 el (XTI)
500 mV/DIV, 25 ns/DIV
ra IC904 r; (XTO)
1 V/DIV, 25 ns/DIV
rs IC912 9 (3Y)
1 V/DIV, 10 Ps/DIV
rd IC912 0 (3B)
1 V/DIV, 10 Ps/DIV
rf IC912 qa (3A)
1 V/DIV, 250 Ps/DIV
rg IC912 qs (4Y)
1 V/DIV, 100 ns/DIV
rh IC912 qd (4B)
1 V/DIV, 100 ns/DIV
rj IC912 qf (4A)
1 V/DIV, 2.5 Ps/DIV
rk IC914 qs (SCK)
2 V/DIV, 50 ns/DIV
rl IC914 qd (BCK)
2 V/DIV, 250 ns/DIV
t; IC914 qg (LRCK)
1 V/DIV, 10 Ps/DIV
81 ns
3.4 Vp-p
40 ns
1.75 Vp-p
40 ns
3 Vp-p
85 ns
290 mVp-p
3.4 Vp-p
375 Ps
3.4 Vp-p
