Sony HCD-GT3D - SECTION 8 ELECTRICAL PARTS LIST; MOTHERBOARD (continuation)

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GT3D
92
R682 1-218-973-11 METAL CHIP 47K 5% 1/16W
R684 1-218-973-11 METAL CHIP 47K 5% 1/16W
R685 1-218-978-11 METAL CHIP 120K 5% 1/16W
R686 1-218-978-11 METAL CHIP 120K 5% 1/16W
R687 1-218-933-11 METAL CHIP 22 5% 1/16W
R688 1-218-929-11 METAL CHIP 10 5% 1/16W
R689 1-218-979-11 METAL CHIP 150K 5% 1/16W
R690 1-218-929-11 METAL CHIP 10 5% 1/16W
R691 1-218-929-11 METAL CHIP 10 5% 1/16W
R692 1-218-969-11 METAL CHIP 22K 5% 1/16W
R693 1-218-989-11 METAL CHIP 1M 5% 1/16W
R694 1-218-973-11 METAL CHIP 47K 5% 1/16W
R696 1-218-973-11 METAL CHIP 47K 5% 1/16W
R697 1-218-973-11 METAL CHIP 47K 5% 1/16W
R698 1-218-973-11 METAL CHIP 47K 5% 1/16W
R700 1-218-969-11 METAL CHIP 22K 5% 1/16W
R701 1-218-929-11 METAL CHIP 10 5% 1/16W
R702 1-218-929-11 METAL CHIP 10 5% 1/16W
R708 1-218-937-11 METAL CHIP 47 5% 1/16W
R709 1-218-937-11 METAL CHIP 47 5% 1/16W
R711 1-218-953-11 METAL CHIP 1K 5% 1/16W
R716 1-218-953-11 METAL CHIP 1K 5% 1/16W
R718 1-218-990-81 SHORT CHIP 0
R719 1-218-929-11 METAL CHIP 10 5% 1/16W
R720 1-218-929-11 METAL CHIP 10 5% 1/16W
R722 1-218-929-11 METAL CHIP 10 5% 1/16W
R723 1-218-929-11 METAL CHIP 10 5% 1/16W
R733 1-216-864-11 SHORT CHIP 0
R747 1-216-864-11 SHORT CHIP 0
R750 1-218-941-81 METAL CHIP 100 5% 1/16W
R751 1-218-941-81 METAL CHIP 100 5% 1/16W
R752 1-218-941-81 METAL CHIP 100 5% 1/16W
R753 1-218-941-81 METAL CHIP 100 5% 1/16W
R756 1-250-515-11 METAL CHIP 6.8K 1% 1/16W
R760 1-218-929-11 METAL CHIP 10 5% 1/16W
R761 1-218-929-11 METAL CHIP 10 5% 1/16W
R762 1-218-929-11 METAL CHIP 10 5% 1/16W
R763 1-216-864-11 SHORT CHIP 0
R791 1-218-990-81 SHORT CHIP 0
R792 1-216-864-11 SHORT CHIP 0
R793 1-216-864-11 SHORT CHIP 0
R794 1-216-864-11 SHORT CHIP 0
R795 1-218-929-11 METAL CHIP 10 5% 1/16W
R796 1-218-929-11 METAL CHIP 10 5% 1/16W
R797 1-218-929-11 METAL CHIP 10 5% 1/16W
R801 1-218-941-81 METAL CHIP 100 5% 1/16W
R802 1-218-933-11 METAL CHIP 22 5% 1/16W
R817 1-218-929-11 METAL CHIP 10 5% 1/16W
R819 1-218-929-11 METAL CHIP 10 5% 1/16W
R820 1-218-929-11 METAL CHIP 10 5% 1/16W
R826 1-218-949-11 METAL CHIP 470 5% 1/16W
R827 1-216-833-11 METAL CHIP 10K 5% 1/10W
R829 1-218-949-11 METAL CHIP 470 5% 1/16W
R830 1-216-833-11 METAL CHIP 10K 5% 1/10W
R831 1-218-941-81 METAL CHIP 100 5% 1/16W
R835 1-218-929-11 METAL CHIP 10 5% 1/16W
R836 1-218-929-11 METAL CHIP 10 5% 1/16W
R837 1-218-933-11 METAL CHIP 22 5% 1/16W
R838 1-218-929-11 METAL CHIP 10 5% 1/16W
R839 1-218-929-11 METAL CHIP 10 5% 1/16W
R840 1-218-933-11 METAL CHIP 22 5% 1/16W
R857 1-216-864-11 SHORT CHIP 0
R859 1-216-864-11 SHORT CHIP 0
R905 1-218-990-81 SHORT CHIP 0
R909 1-218-990-81 SHORT CHIP 0
R911 1-218-985-11 METAL CHIP 470K 5% 1/16W
R912 1-218-985-11 METAL CHIP 470K 5% 1/16W
R913 1-218-975-11 METAL CHIP 68K 5% 1/16W
R914 1-218-975-11 METAL CHIP 68K 5% 1/16W
R915 1-208-699-11 METAL CHIP 4.7K 0.50% 1/16W
R916 1-208-699-11 METAL CHIP 4.7K 0.50% 1/16W
R935 1-250-468-11 METAL CHIP 75 1% 1/16W
R937 1-218-941-81 METAL CHIP 100 5% 1/16W
R938 1-216-864-11 SHORT CHIP 0
R939 1-218-965-11 METAL CHIP 10K 5% 1/16W
R940 1-218-941-81 METAL CHIP 100 5% 1/16W
R943 1-218-933-11 METAL CHIP 22 5% 1/16W
R944 1-218-933-11 METAL CHIP 22 5% 1/16W
R948 1-218-990-81 SHORT CHIP 0
R949 1-216-809-11 METAL CHIP 100 5% 1/10W
R950 1-216-797-11 METAL CHIP 10 5% 1/10W
R951 1-216-797-11 METAL CHIP 10 5% 1/10W
R952 1-216-797-11 METAL CHIP 10 5% 1/10W
R953 1-218-950-11 METAL CHIP 560 5% 1/16W
R954 1-218-989-11 METAL CHIP 1M 5% 1/16W
R955 1-216-819-11 METAL CHIP 680 5% 1/10W
R957 1-216-797-11 METAL CHIP 10 5% 1/10W
R959 1-216-797-11 METAL CHIP 10 5% 1/10W
R963 1-218-929-11 METAL CHIP 10 5% 1/16W
R964 1-218-929-11 METAL CHIP 10 5% 1/16W
R965 1-218-941-81 METAL CHIP 100 5% 1/16W
R966 1-218-929-11 METAL CHIP 10 5% 1/16W
R978 1-218-990-81 SHORT CHIP 0
R980 1-218-990-81 SHORT CHIP 0
R981 1-218-990-81 SHORT CHIP 0
R982 1-218-990-81 SHORT CHIP 0
R995 1-218-990-81 SHORT CHIP 0
R996 1-218-990-81 SHORT CHIP 0
< COMPOSITION CIRCUIT BLOCK >
RB301 1-234-370-21 RES, NETWORK 22 (1005X4)
RB302 1-234-370-21 RES, NETWORK 22 (1005X4)
RB303 1-234-370-21 RES, NETWORK 22 (1005X4)
RB304 1-234-370-21 RES, NETWORK 22 (1005X4)
RB305 1-234-370-21 RES, NETWORK 22 (1005X4)
RB306 1-234-370-21 RES, NETWORK 22 (1005X4)
RB307 1-234-370-21 RES, NETWORK 22 (1005X4)
RB308 1-234-370-21 RES, NETWORK 22 (1005X4)
RB309 1-234-370-21 RES, NETWORK 22 (1005X4)
< THERMISTOR >
TH571 1-804-949-11 THERMISTOR, NTC (SMD)
< VIBRATOR >
X101 1-814-273-11 QUARTZ CRYSTAL UNIT (32.768kHz)
X102 1-814-767-11 QUARTZ CRYSTAL UNITS (13.333MHz)
X103 1-814-466-11 QUARTZ CRYSTAL UNITS (12.288MHz)
X104 1-814-356-11 QUARTZ CRYSTAL UNIT (48MHz)
X301 1-814-023-11 QUARTS CRYSTAL UNIT (27MHz)
MOTHERBOARD
Ver. 1.1
