Sony HCD-GT3D - SECTION 8 ELECTRICAL PARTS LIST; MS-476 BOARD; OPTICAL BOARD; SPLITTER BOARD

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-GT3D
93
MOTHERBOARD
MS-476 OPTICAL SPK_HLED SPLITTER
X600 1-814-365-11 QUARTZ CRYSTAL UNITS (12MHz)
X602 1-814-130-11 QUARTZ CRYSTAL UNIT (24.576MHz)
*************************************************************
MS-476 BOARD
************
When the MS-476 board is defective, exchange the entire LOADING COMPLETE
ASSY (T).
*************************************************************
OPTICAL BOARD
*************
< CAPACITOR >
C3301 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C3303 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
< IC >
IC3300 6-600-827-01 IC JSR1124 (OPTICAL IN TV)
< JUMPER RESISTOR >
JR3300 1-216-864-11 SHORT CHIP 0
< RESISTOR >
R3300 1-216-864-11 SHORT CHIP 0
R3301 1-216-864-11 SHORT CHIP 0
*************************************************************
SPK_HLED BOARD
***************
< CONNECTOR >
CN4000 1-580-057-11 PIN, CONNECTOR (SMD) 4P
< DIODE >
D4000 6-504-103-01 DI LA CN5M-GAHA-24-1 (R)
D4001 6-504-102-01 DI LD CN5M-4Q4R-35-1 (B)
D4002 6-504-104-01 DI LT CN5M-GAHB-25-1 (G)
*************************************************************
SPLITTER BOARD
**************
< CONNECTOR >
CN3400 1-820-123-51 CONNECTOR, FFC/FPC 25P
CN3401 1-785-468-51 CONNECTOR, FFC/FPC 13P
CN3402 1-820-113-51 CONNECTOR, FFC/FPC 11P
< RESISTOR >
R001 1-216-295-91 SHORT CHIP 0
R002 1-216-295-91 SHORT CHIP 0
R003 1-216-295-91 SHORT CHIP 0
R004 1-216-864-11 SHORT CHIP 0
R005 1-216-864-11 SHORT CHIP 0
R006 1-216-295-91 SHORT CHIP 0
R007 1-216-295-91 SHORT CHIP 0
R008 1-216-295-91 SHORT CHIP 0
*************************************************************
MISCELLANEOUS
**************
55 1-849-009-11 WIRE (FLAT TYPE) (11 CORE)
151 1-849-011-11 WIRE (FLAT TYPE) (19 CORE)
153 1-849-010-11 WIRE (FLAT TYPE) (25 CORE)
* 202 3-703-150-11 CLAMP
0 203 1-855-006-41 FAN, DC
0 205 1-844-234-21 AC INLET
0 206 A-2061-350-A SMPS BOARD, COMPLETE
211 1-859-087-11 LOUDSPEAKER (20CM)-087-11
* 213 1-500-082-11 CLAMP, SLEEVE FERRITE (RU, EA, MY, AUS, E4)
251 1-849-013-11 WIRE (FLAT TYPE) (13 CORE)
252 1-849-014-11 WIRE (FLAT TYPE) (10 CORE)
253 1-492-699-11 BLUETOOTH MODULE
256 1-849-015-11 WIRE (FLAT TYPE) (6 CORE)
257 8-989-602-00 RC-S730 (WW)
351 A-1896-391-B LOADING COMPLETE ASSY (T)
(including MS-476 board)
0 354 A-2046-956-A SERVICE, OPTICAL DEVICE(7G)
355 1-469-829-11 CORE, FERRITE
356 1-849-012-11 WIRE (FLAT TYPE) (24 CORE)
357 1-849-016-11 WIRE (FLAT TYPE) (5 CORE)
Note : If cable, fl exible fl at and wire (fl at type) is replaced,
install it after bending it in the same form as that
before replacement.
