Sony ICP-X7000

ICP-X7000
1-24 (E)
5. Insert one projection of the supplied cap pull tool into
the groove of the switch cover.
n
Do not insert both projections simultaneously.
Cap pull tool
Projection
Switch cover
Groove
6. In the same way, insert the other projection into the
other groove.
n
Carefully insert the projections at the end of the cap
pull tool into the grooves of the switch cover so as not
to damage the switch cover and the panel by the pro-
jections.
Cap pull tool
Projection
Switch cover
Groove
7. Hold and pull the cap pull tool in the direction of arrow
to detach the switch cover.
Cap pull tool
Switch cover
