ICP-X7000
1-82 (E)
Releasing association
The following describes how to release the association of NS-BUS remote control panel (MKS-R3210/
MKS-R1620) with the switcher control panel.
Procedure
1. Select the [Configuration] radio button of “Mode” on the AUX Remote Panel Config window.
2. Select the checkbox of NS-BUS remote control panel whose association you want to release from the
PNL1 to PNL4 field.
3. Select the destination (AUX Remote Panel) from the [Move to] drop-down list.
4. Click the [Execute] button.
The setting is executed.
Deleting detected NS-BUS remote control panel
The following describes how to delete the NS-BUS remote control panel (MKS-R3210/MKS-R1620)
displayed in the AUX Remote Panel field.
Procedure
1. Select the [Delete] radio button of “Mode” on the AUX Remote Panel Config window.
2. Select the checkbox of NS-BUS remote control panel to be deleted from the AUX Remote Panel
field.
3. Click the [Execute] button.
The setting is executed.
To Next Page
