3-2. SERVICE Menu List
3-2-1. MAINTENANCE Menu
Menu Submenu Set value Description
Test Saw — On, Off Turns On or Off the Test Saw.
Auto BLK Balance — Execute, Cancel Starts the auto black balance adjustment.
Black Shading Setting On, Off Turns On or Off the black shading correction.
Channel Sel G, B, R Selects the channel to adjust the black shading.
(The present set values of H Saw, H Para, V Saw,
and V Para for the selected channel are displayed
automatically.)
H Saw –99 to +99 Adjusts the black shading H Saw correction level.
H Para –99 to +99 Adjusts the black shading H Para correction level.
V Saw –99 to +99 Adjusts the black shading V Saw correction level.
V Para –99 to +99 Adjusts the black shading V Para correction level.
Auto BLK Shad Execute, Cancel Starts the auto black shading.
White Shading Setting On, Off Turns On or Off the white shading correction.
Channel Sel G, B, R Select the channel to adjust the white shading. (The
present set values of H Saw, H Para, V Saw, and
V Para for the selected channel are displayed au-
tomatically.)
H Saw –99 to +99 Adjusts the white shading H Saw correction level.
H Para –99 to +99 Adjusts the white shading H Para correction level.
V Saw –99 to +99 Adjusts the white shading V Saw correction level.
V Para –99 to +99 Adjusts the white shading V Para correction level.
Flare G Flare –99 to +99 Adjusts the G-ch flare correction level.
B Flare –99 to +99 Adjusts the B-ch flare correction level.
R Flare –99 to +99 Adjusts the R-ch flare correction level.
Auto FB Adjust — Execute, Cancel Starts the auto flange back adjustment.
Note
This menu should be carried out with 60i or
50i to enhance the adjustment accuracy.
3-2-2. RPN CORRECT Menu
Menu Submenu Set value Description
Auto Detection — — Starts automatic detection of RPN.
Channel — R, G, B Specifies color components of pixels to be correc-
ted.
Cursor — On, Off Turns On or Off the correction point indicator cur-
sor.
Cursor H Position — 1 to 1920 Displays and moves the horizontal address of the
correction point indicator cursor.
Cursor V Position — 1 to 1080 Displays and moves the vertical address of the cor-
rection point indicator cursor.
Cursor Next — — Moves the correction point indicator cursor to the
next address.
Cursor Prev — — Moves the correction point indicator cursor to the
previous address.
Record — Execute, Cancel Registers the RPN.
Continued
