Sony PMW-EX280 - AXM-48 Board

3. Remove the two precision screws (M2 x 4) and the nut to detach the RM-237/RM-238 board.
Precision screws
(M2 x 4)
RM-237/RM-238 board
Nut
HN-404 board
CN100
4. Remove the flexible board of RM-238 board from the connector CN100 on the RM-237 基板.
RM-238 board
RM-237 board
Flexible board
CN100
5. Install the removed parts by reversing steps of removal.
2-13-9. AXM-48 Board
Preparation
1. Remove the handle (upper) case assembly. (Refer to “2-13-2. Control Switch Block (GZ92000)”.)
2. Remove the control panel assembly. (Refer to “2-13-3. MIC Unit”.)
PMW-200/PMW-EX280
2-33
