ID Intended device Diagnosis Error value Type1/2 Note
0x25 ExpressCard ExpressCard power
switch ON/OFF control
Non-installation "-6" is
always returned.
1 Startup must be com-
pleted
0x26 (SlotB) ExpressCard overcur-
rent detection
Non-installation "-6" is
always returned.
1 Startup must be com-
pleted
0x23 LED LED blink check Refer to "Details of di-
agnosis"
1 Startup must be com-
pleted
0x24 LED LED blink check Refer to "Details of di-
agnosis"
1 Startup must be com-
pleted
0x30 Torino (video signal
line)
Video encoding Refer to "Details of di-
agnosis"
1 Startup must be com-
pleted
0x31 Torino (audio signal
line)
Audio encoding Refer to "Details of di-
agnosis"
1 Startup must be com-
pleted
0x32 4-bit signal line Transfer data (from
Ramiel) check
Refer to "Details of di-
agnosis"
1 Startup must be com-
pleted
0x01 — Command response on-
ly
Normal end "0" is al-
ways returned.
2 Startup must be com-
pleted
Details of diagnosis
Error value Diagnosis
0 Normal end
-1 Hardware error detected
-4 Service tool not detected
-6 Non-installation
Item4 (Audio block diagnosis)
The audio block diagnosis tests the following content.
ID Diagnosis Error value Type1/2 Note
0x11 Audio memory area check (in the
CXD9211CGG (Main T-one))
-1: Memory read/write comparison
error
1, 2 —
0x12 FPGA (ANDA) access check
(AU-342 board IC501 A6 pin, A4
pin, A7 pin, A5 pin)
-1: Register set value acquisition er-
ror
1, 2 —
0x13
DSP-only DPSRAM check Other than 0: DPSRAM check error 1, 2 —
Error number of failed diagnosis is
displayed as an error value. For error
values, refer to "Error values of di-
agnosis items ID 0x13".
0x14
Serial audio data check in the audio
block
Other than 0: Mismatch between out-
put data and input data
1, 2 This diagnosis using an
internal microphone
may fail depending on
disturbing noise.
Error number of failed diagnosis is
displayed as an error value. For error
values, refer to "Error values of di-
agnosis items ID 0x14".
0x15
Serial audio data reception check of
IC1700 on the DCP-56 board
Other than 0: Mismatch between out-
put data and input data
1, 2 —
Error number of failed diagnosis is
displayed as an error value. For error
values, refer to "Error values of di-
agnosis items ID 0x15".
PMW-200/PMW-EX280
3-8
