242
Executing an AUX mix (cross-point
control block)
This section describes an AUX mix using the AUX1 bus
and AUX2 bus as an example.
This switches from the image cur
rently output on the
AUX1 bus to a new image using an AUX mix.
• The button used to execute an AUX mix must be
assig
ned to the cross-point pad/function button section
of the cross-point control block beforehand.
For details about assigning buttons in the
cross-point
pad, see “Setting a Cross-Point Pad” (page 405).
For details about assigning buttons in the
function
button section, see “Assigning Control Panel Buttons”
(page 397).
• The AUX mix transition rate is configured using the
menu.
For details about settings, see “Executing an AUX mix
(menu)” (page 242).
1
Press the [AUX MIX] button, turning it on.
Use the [AUX MIX] button for the cross-point button
row assigned
with the AUX1 bus.
2
Select an image for after the transition in the cross-
point button row assigned with the AUX1 bus.
The image during the transit
ion is output on the
AUX1 bus.
The selected image is output on the AUX2 bus.
When the output signal conversion format is 2160P
2SI
3G, the image during the transition is also output
on the even-numbered AUX bus.
Executing an AUX mix (AUX bus control
block)
This section describes an AUX mix using the AUX1 bus
and AUX2 bus as an example.
This switches from the image cur
rently output on the
AUX1 bus to a new image using an AUX mix.
• The button used to execute an AUX mix must be
a
ssigned to the cross-point pad of the AUX bus control
block beforehand.
For details about assign
ing buttons, see “Setting a
Cross-Point Pad” (page 405).
• The AUX mix transition rate is configured using the
menu.
For details about settings, see “Executing an AUX mix
(menu)” (page 242).
1
Press the [AUX MIX] button, turning it on.
When second delegation mode is enabled and the
A
UX1 bus is selected using the 1st row delegation
buttons, use the [AUX MIX] button for the 3rd row.
When the AUX1 bus is selected using the 2nd row
delegation buttons, use the [AUX MIX] button (2nd
Aux Mix) for the 4th row.
2
Select an image for after the transition in the cross-
point button row assigned with the AUX1 bus.
The image during the transition is output on the
A
UX1 bus.
The selected image is output on the AUX2 bus.
When the output signal conv
ersion format is 2160P
2SI 3G, the image during the transition is also output
on the even-numbered AUX bus.
Executing an AUX mix (menu)
This section describes an AUX mix using the AUX1 bus
and AUX2 bus as an example.
This switches from the image
currently output on the
AUX1 bus to a new image using an AUX mix.
1
Open the Home > Other Effects > Aux Bus > Aux Xpt
menu (18102.11).
2
Select the AUX1 bus.
3
Press the [Edit] button.
The AUX1 bus signal selection window appears.
4
In [Aux Mix], set the [On] radio button to the on state.
To disable an AUX mix, set the
[Off] radio button to
the on state.
To set the transition rate
Press the button on the right of the [On] radio button
a
nd enter a transition rate in the numeric keypad
window.
To switch the video signal and key signal
To select a video signal, set the [Video] radio button
for [Se
lect Source Type] to the on state.
To select a key signal, set the [Key] radio button for
[Sel
ect Source Type] to the on state.
5
Execute an AUX mix using the cross-point selection
buttons.
Select a tab to change the button to display.
