327
To release a macro attachment set to a fader
lever
Press and hold the [PRE MACRO] button or [POST
MACR
O] button in the cross-point control block and
press the [LIMIT SET] button or [PRIOR SET] button in
the transition control block/transition control block
(simple type).
You can also release a macro attachment setting using the
menu.
For details, see “Displaying a Macro Attachment List”
(page 327).
Setting the macro attachment
configuration mode of a cross-point
button
The following two modes can be selected for a macro
attachment set to a cross-point button.
Button number mode: Assign a mac
ro attachment for the
combination of bus and button number.
Pair number mode: Assign a macro attachment for the
co
mbination of bus and pair number.
• If the macro attachment config
uration mode is changed,
the macro attachment assigned to a cross-point button is
deleted.
• In pair number mode, the following occurs.
– If the same pair number is assigned
to multiple cross-
point buttons, pressing any of the buttons executes the
macros of all buttons to which the same pair number
is assigned.
– If the same pair number is assigned
to multiple cross-
point buttons, releasing the macro attachment of any
of the buttons releases the macro attachment of all
buttons to which the same pair number is assigned.
– If you change the pair number assignment to a
different cross-
point button, the macro attachment
setting is also transferred.
• When macro attachment data is loaded, the button
nu
mber mode or pair number mode setting is
overwritten.
1
Open the Home > Register > Macro > Attachment
menu (18307.31).
2
In the [Xpt Attachment Mode] group, select a
configuration mode.
Button Mode:
Button number mode
Pair Mode: Pai
r number mode
3
Check the message, then press [OK].
Displaying a Macro Attachment List
You can check the information for a button/fader lever to
which a macro attachment is set in list view.
1
Open the Home > Register > Macro > Attachment
menu (18307.31).
2
Display the target control block.
Select a tab to change the control block to display.
[M/E-1] tab to [M/E-5] tab,
[P/P] tab: Switcher
bank cross-point control block and transition
control block/transition control block (simple
type)/independent key transition control block
[Aux] tab:
AUX bus control block (ICP-X7000 only)
[Trackball] tab: Device con
trol block (ICP-X1000
series only)
[Trackball/Key Fader] tab:
Device control block
and key fader control block (ICP-X7000 only)
A list of the macro attachments set
to the buttons of
the selected control block is displayed.
You can check the following information in a macro
at
tachment list.
•Block name
Displays the name of the control block on which macro
a
ttachments are set.
• Buttons to which a macro attachment is set
• Register number
•Register name
• Link mode
For details about macro attachment lists, see “Macro
Attachment Lists” (page 476).
Macro attachments set to the
following buttons in the
cross-point control block may not be displayed in the list.
• DME utility 1 bus and 2 bus cross-point buttons in
utility
bus mode
• DME utility 1 bus and 2 bus cross-point buttons in key/
AUX
bus delegation mode
Releasing a macro attachment
1
Open the Home > Register > Macro > Attachment
menu (18307.31).
2
Display the target control block.
Select a tab to change the control block to display.
[M/E-1] tab to [M/E-5] tab,
[P/P] tab: Switcher
bank cross-point control block and transition
control block/transition control block (simple
type)/independent key transition control block
Note
Notes
Note
