Utility/Shotbox Control Block
The utility/shotbox control block is used to execute
functions assigned to memory recall buttons, edit and
execute effect timelines, edit macros, display the
transition rate, and other tasks.
a Mod
e selection buttons / operation buttons / bank
selection buttons (assignable buttons)
You can assign mode/bank selection buttons and effect
ti
meline operation buttons in the Home > Setup > Panel >
Module > Button Assign menu (19104.21).
For details about assign
ing buttons, see “Assigning
Control Panel Buttons” (page 397).
Mode selection buttons
Effect timeline operation buttons
b
a
Function name Button name Description
Transition Rate 1
to Tran
sition Rate
3
TRANS RATE1
to TRANS
RATE3
Switches the memory
recall section to
transition rate display
mode.
You can press a
memory r
ecall button
in transition rate
display mode to enter
a transition rate in the
numeric keypad
control block.
Keyframe/Macro
Edit
KF MCRO EDIT Switches the memory
recall section t
o effect
timeline/macro edit
mode.
You can edit an effect
timeline register/
macro register
recalled using the
numeric keypad
control block.
Function name Button name Description
Effect Loop EFF LOOP Repeatedly executes
an effe
ct timeline.
Normal NORM Sets the effect
t
imeline execution
direction to normal
(from beginning to
end).
Normal/Reverse NORM/REV Sets the effect
t
imeline execution
direction to normal/
reverse (toggles each
time execution
finishes).
Reverse REV Sets the effect
t
imeline execution
direction to reverse
(from end to
beginning).
Rewind REWIND When the execution
directio
n is normal,
moves the effect
timeline to the start
point.
When the execution
direction is rever
se,
moves the effect
timeline to the stop
point.
Run RUN Executes an effect
ti
meline.
