Sony XVS-G1

407
a) “Row-n” is Row-1 to Row-4.
Setting the home page
You can set the page to display when the [HOME] button
in a cross-point pad is pressed.
1 Open the Home > Setup > Panel > Xpt Module > Xpt
Pad Button Assign menu (19104.36).
2 In the [Select Bank] group, select the target switcher
bank/AUX bus control block (AUX 1, AUX 2) to set.
Place a check mark for the switcher bank/AUX bus
c
ontrol block to select.
You can also select and set mult
iple switcher banks or
AUX bus control blocks simultaneously.
• A switcher bank and AUX bus control block cannot
be sele
cted simultaneously.
• In multi program 2 mode, main and sub can be set
sep
arately. When a switcher bank main and sub are
shared, the setting is also shared.
3 Display the page you want to set as the home page.
Select a tab to change the page (Page 1 to Page 14) to
display.
4 Set the [Home Page Enable] switch to the on state.
The selected page is set as the home page.
Changing the button image for the control
panel button display
The names of functions assigned to buttons are displayed
in the button image in [Button Assign].
You can change the button image display to the color and
na
me of buttons in the cross-point pad in the control
panel.
• The button image display set
tings are common to all
pages in the cross-point pad.
• The display of a button status (lit/not lit), white frame
fo
r buttons configured with page recall function, and
current status are not reflected in the [Button Assign]
button image. The button name displayed in the control
panel may vary depending on the button.
1 Open the Home > Setup > Panel > Xpt Module > Xpt
Pad Button Assign menu (19104.36).
2 In the [Select Bank] group, select the target switcher
bank/AUX bus control block (AUX 1, AUX 2) to set.
Place a check mark for the switcher bank/AUX bus
co
ntrol block to select.
You can also select and set mu
ltiple switcher banks or
AUX bus control blocks simultaneously.
• A switcher bank and AUX bus control block cannot
be
selected simultaneously.
• In multi program 2 mode, main and sub can be set
separate
ly. When a switcher bank main and sub are
shared, the setting is also shared.
3 Set the [Button Reference Image] switch to the on
state.
Returning cross-point pad settings to the
defaults
1 Open the Home > Setup > Panel > Xpt Module > Xpt
Pad Button Assign menu (19104.36).
2 In the [Select Bank] group, select the target switcher
bank/AUX bus control block (AUX 1, AUX 2) to set.
Place a check mark for the switcher bank/AUX bus
co
ntrol block to select.
You can also select and set mu
ltiple switcher banks or
AUX bus control blocks simultaneously.
• A switcher bank and AUX bus control block cannot
be
selected simultaneously.
• In multi program 2 mode, main and sub can be set
separate
ly. When a switcher bank main and sub are
shared, the setting is also shared.
3 Press the [Default Recall] button.
Row-n Xpt Btn
No.296
296 77 P/P Out5
Row-n Xpt Btn
No.297
297 109 M/E-4 Out5
Row-n Xpt Btn
No
.298
298 117 M/E-5 Out5
Row-n Xpt Btn
No
.299
299 299 (black signal)
Row-n Xpt Btn
No
.300
300 300 (black signal)
Notes
Function name
a)
Cross-
point
button
number
V/K pair
number
Signal
Notes
Notes
Notes
