Sony XVS-G1

41
Router operation mode
Uses the 1st row and 2nd delegation buttons to select a
d
estination, and the 3rd row and 4th row cross-point
buttons to select a source.
For details, see “Router Operations (AUX Bus Control
Block)” (page 231).
b Di
splay
In AUX bus operation mode, the following information is
disp
layed.
• Settings of buttons on the 1st row to 4th row (bus name
or sign
al name assigned to the button)
• Macro register name of macro attachment assigned to
t
he 1st row to 4th row buttons
• Signal name selected by the bus on the 1st row to 2nd
ro
w delegation buttons
In router operation mode, the
following information is
displayed.
• Settings of buttons on the 1st row to 4th row
(d
estination name or source name assigned to the
button)
• Source name selected by the de
stination on the 1st row
to 2nd row delegation buttons
When the [SHIFT] button function is set, “SHFT”
appe
ars on the display. When the shifted state is selected,
“SHFT” is displayed highlighted, and the button
information also toggles to show the shifted state display.
Display mode
Six types of display mode can be set according to the
info
rmation to display. You can switch the mode using
the display mode button assigned to the cross-point pad.
The display can also be subdivided (top and bottom) to
display two pieces of information.
For details, see “Setting the Display” (page 404).
c C
ross-point indicators
When lit, these indicate the so
urce color of the video
signal assigned to buttons on the 3rd row.
If a signal cannot be selected, because a signal is not
assi
gned or the inhibit setting is set, the indicator is not lit.
You can disable the cross-point indicators so that they do
not turn
on.
For details, see “Setting the on/off state of
cross-point
indicators” (page 404).
In router operation mode, cross-poi
nt indicators are not
used.
d C
ross-point pad (assignable buttons)
You can assign functions, such as settings an
d operations,
of the cross-point button rows in the Home > Setup >
Panel > Xpt Module > Xpt Pad Button Assign menu
(19104.36).
You can configure up to 14 pages (page 1 to page 14) of
set
tings, where each page contains functions assigned to
the 15 cross-point pad buttons as a group.
For details about assigning buttons, see “Setting a Cross-
Point Pad” (page 405).
3rd row • When second delegation mode is enabled,
selects the signal for the bus assigned by
the 1st row delegation buttons.
• When second delegation mode is disabled,
se
lects the signal for the bus assigned by
the 1st row or 2nd row delegation buttons.
You can select the signal in the shifted state
wh
ile pressing the shift button.
4th row • When second delegation mode is enabled,
se
lects the signal for the bus assigned by
the 2nd row delegation buttons.
• When second delegation mode is disabled,
selects
the signal for the bus in the shifted
state assigned by the 1st row or 2nd row
delegation buttons.
Name Description
1st row • When second delegation mode is enabled,
se
lects the destination to assign to the 3rd
row.
• When second delegation mode is disabled,
se
lects the destination (destination in
unshifted state of delegation buttons) to
assign to the 3rd row and 4th row.
You can select the destination in the shifted
state whil
e pressing the shift button.
2nd row • When second delegation mode is enabled,
se
lects the destination to assign to the 4th
row.
• When second delegation mode is disabled,
se
lects the destination (destination in
shifted state of delegation buttons) to assign
to the 3rd row and 4th row.
3rd row • When second delegation mode is enabled,
se
lects the source for the destination
assigned by the 1st row delegation buttons.
• When second delegation mode is enabled,
se
lects the source for the destination
assigned by the 1st row or 2nd row
delegation buttons.
You can select the source in the shifted
state whil
e pressing the shift button.
4th row • When second delegation mode is enabled,
se
lects the source for the destination
assigned by the 2nd row delegation buttons.
• When second delegation mode is enabled,
se
lects the source for the destination in the
shifted state assigned by the 1st row or 2nd
row delegation buttons.
Name Description
Note
