60
ICP-X7000 Control Panel
Bottom view
a DC IN connector
Connect to the suppli
ed AC adaptor.
b LA
N connector (RJ-45, PoE+, 1000BASE-T
compliant)
Connect to the switcher syst
em network via an Ethernet
switch.
Operation without using the AC adaptor is supported
usi
ng a PoE+ (Power over Ethernet Plus) compatible
Ethernet switch.
For details about PoE+ (Power over Et
hernet Plus)
compatible Ethernet switches that can be used, consult
your Sony representative.
a
b
ICP-X7000 Integrated Control Panel
MKS-X7075 Extension Adaptor
