10 PC requirements
206718 rev 9
SOREDEX 117
* For the PC requirements of the 3D viewing software
consult the 3D software manuals.
System requirements and connections
- The PC and any other external device(s)
connected to the system must meet the IEC 60950
standard (minimum requirements). Devices that do
not meet the IEC 60950 standard must not be
connected to the system as they may pose a threat
to operational safety.
- The PC and any other external devices must be
connected in accordance with IEC 60601-1-1.
- The x-ray unit must be connected to it’s own
separate power supply. The PC and any other
external devices must NOT be connected to the
same power supply as the x-ray unit.
- The unit shall be connected directly to the
acquisition PC with an Ethernet cable. Connection
through the LAN-network of the site is not allowed.
Two network ports are needed in the PC in order to
connect also to the site network.
- Position the PC and any other external device at
least 1.5 m (60”) from the x-ray unit so that the
patient cannot touch the PC or any other external
device while being x-rayed.
- The PC and any other external devices shall not be
connected to an extension cable.
- Multiple extension cables shall not be used.
- Do not position the PC where it could be splashed
Minimum PC requirements for 2D/3D Viewing workstation *
Processor 2.0 GHz dual core, or better
Memory 3 Gigabytes RAM, or more
Graphics board 1GB or more memory
(integrated graphics are not supported)
Hard disk 3 GB free space, or more
Network Gigabit Ethernet 1000Base-T
(recommended) or Fast Ethernet
100Base-TX
Operating system Windows 7, Windows 8 / 8.1 or Windows 10
Display 19" LCD display, 1280 x 1024, or better
