SPX FLOW 030-U3 User Manual

Waukesha Cherry-Burrell
®
Brand Universal 3 Pump Parts List
11/2018 95-03103 Page 103
006, 015, 018-U3 Parts
See notes on page page 102.
ITEM NO. DESCRIPTION
QTY.
PER
PUMP
PART NO. NOTES
1
Pump Body 1 See Note 1 1
006-U3 Pump Cover 1 138283+
015-U3 Pump Cover 1 138242+
018-U3 Pump Cover 1 138284+
3
Gear Case, SS, Model 006, 015, 018 1 138116+
4
Gear Case Cover, SS 1 102280+
5
Gear, Drive Shaft, Spur 1 107997+
6
Gear, Short Shaft, Spur 1 107997+
7
006-015-018-U3 Drive Shaft 1 138240+ 41
8
006-015-018-U3 Short Shaft 1 138239+ 41
006-U3 Rotor, Twin Wing, Alloy 88 2 138253+ 2
006-U3 Rotor, Twin Wing, 316SS 2 138257+ 2
015-U3 Rotor, Twin Wing, Alloy 88 2 138263+ 2
015-U3 Rotor, Twin Wing, 316SS 2 138267+ 2
018-U3 Rotor, Twin Wing, Alloy 88 2 138273+ 2
018-U3 Rotor, Twin Wing, 316SS 2 138277+ 2
9
A
Rotor drive pin (not shown) 2 138646+ 2
006-U3 Stud 8 138290+
015-U3 Stud 8 138291+
018-U3 Stud 8 138292+
11
Hex Nut 8 108369+
12
Oil Seal, Gear Case Cover 1 000030016+
13
Oil Seal, Gear Case Rear 2 000030017+
14
Grease Seal, Bearing Retainer 2 121679+
15
Bearing, Rear 2 015035000+
16
Bearing, Front 2 101714+
17
Key, Gear 2 015037000+
20
Dowel Pin, Cover Side, .245" x .85" 1 137001+ 43
21
Dowel Pin, Gear Case Side, .245" x 1.0" 1 124581+ 44
22
Dowel Pin, Cover Side, .308" x .85" 1 137002+ 43
23
Dowel Pin, Gear Case Side, .308" x 1.0" 1 124582+ 44
Oil Plug, M20 x 1.5" 5 137169+
*
O-Ring, Buna (for oil plug) 5 N70114
Oil Level Indicator, M20 x 1.5" 1 137435+
25
Silicone Sealant 1 000142301+
26
Nut, Rotor 2 138243+
O-Ring, Rotor Nut, EPDM 2 E70121
*
O-Ring, Rotor Nut, FKM 2 V70121
O-Ring, Rotor Nut, FFKM 2 K70121
PL5060-CH152
4
24
26A
2
9
10
