SPX FLOW 030-U3 User Manual

Waukesha Cherry-Burrell
®
Brand Universal 3 Pump Maintenance
11/2018 95-03103 Page 93
Reference Tables
Table 21: Universal 3 Wrench Size
Gear Nut Driver
Tool
Model Rotor Nut
Body Retaining
Cap Screw
Cover Nut
006, 015, 018 15/16"
3/16" 5/8"
109281+
030, 040 1-1/4" 109282+
045, 060 1-5/8" 1/4"
7/8"
109283+
130 2-1/4"
5/16"
110304+
180, 220 2-3/8" 1" 114702+
Table 22: Torque Values
Model
Gear Nut Rotor Nut Cover Nut
Seal Housing
Bolt
006, 015, 018
120 ft-lb
163 N·m
50 ft-lb
68 N·m
7 ft-lb
10 N·m
7.4 ft-lb
10 N·m
030, 040
120 ft-lb
163 N·m
11 ft-lb
15 N·m
14.8 ft-lb
20 N·m
045, 060
140 ft-lb
190 N·m
250 ft-lb
339 N·m
56 ft-lb
76 N·m
130
25 ft-lb
34 N·m
180, 220
230 ft-lb
312 N·m
325 ft-lb
441 N·m
110 ft-lb
149 N·m
210, 320
320 ft-lb
434 N·m
375 ft-lb
508 N·m
158 ft-lb
214 N·m
Table 23: Arbor or Hydraulic Press Tonnage (Approximate)
Model
Shaft Front Bearing Rear Bearing
IN OUT ON OFF ON OFF
006, 015, 018 .25 .50 .50 1.00 .50 1.00
030, 040 .25 1.00 .50 1.00 .50 1.00
045, 060 .50 1.00 2.00 5.00 3.00 5.00
130 .50 1.00 5.00 15.00 5.00 15.00
180, 220 .50 1.00 5.00 2.00 5.00 2.00
