SPX FLOW 030-U3 User Manual

Parts List Waukesha Cherry-Burrell
®
Brand Universal 3 Pump
Page 130 95-03103 11/2018
U3 Shaft and Bearing Assemblies
Note:
Assembly includes items 7 or 8 (drive or short shaft), 15 (rear bearing), 16 (front bearing), 17 (gear key), and 29 (gear to
rear bearing spacer). See model-specific parts list page for drawing.
DESCRIPTION
QTY. PER
PUMP
PART
NO.
006-015-018-U3 Drive Shaft & Bearing Assy. 1 139809+
006-015-018-U3 Short Shaft & Bearing Assy. 1 139810+
030-040-U3 Drive Shaft & Bearing Assy. 1 139811+
030-040-U3 Short Shaft & Bearing Assy. 1 139812+
045-060-130-U3 Drive Shaft & Bearing Assy. 1 139813+
045-060-130-U3 Short Shaft & Bearing Assy. 1 139814+
180-220-U3 Drive Shaft & Bearing Assy. 1 139815+
180-220-U3 Short Shaft & Bearing Assy. 1 139816+
210-320-U3 Drive Shaft & Bearing Assy. 1 139817+
210-320-U3 Short Shaft & Bearing Assy. 1 139818+
PL5060-CH165
