SPX FLOW 030-U3 User Manual

Waukesha Cherry-Burrell
®
Brand Universal 3 Pump Parts List
11/2018 95-03103 Page 105
006, 015, 018-U3 Parts
Notes:
* Recommended spare parts
For standard seals, see page 123. For specialty seals, see page 124. For standard seal kits, see page 127.
3. See “Replacement Labels” on page 12 for label detail.
ITEM NO. DESCRIPTION
QTY.
PER
PUMP
PART NO. NOTES
27
Shim Kit 2 117889+
29
Spacer, Gear to Rear Bearing 2 015055000+
30
Bearing Spacer 2 101814+
32
Bearing Retainer, Front 2 120332+
33
A
1/4-20 x 3/4" HHCS, Gear Case Cover 6 30-58
33B
1/4-20 x 3/4" HHCS, SS Bearing Retainer 8 30-58
33C
1/4" Flat Washer 6 43-27
34
Dowel Bushing, Upper 1 AD0116000
35
Dowel Bushing, Lower 1 AD0116100
006-015-018-U3 Cover Gasket, FKM 1 137422+
*
006-015-018-U3 Cover Gasket, FFKM 1 137423+
006-015-018-U3 Cover Gasket, EPDM 1 137424+
39
Lock washer, Gear 2 STD136005
41
Locknut, Gear 2 STD236005
42
Mounting Foot 006-015-018-U3 SS 1 102284+
43
Plastic Cap Plug 6 000121003+
44
5/16-18 x 1" SHCS, SS 4 30-525
006-U3 Body Retaining Screw 2 30-211
015-U3 Body Retaining Screw 2 30-543
018-U3 Body Retaining Screw 2 30-613
46
Eye Bolt, 5/16-18 x 1/2" SS 2 30-719
Key, Coupling - 3/16 x 3/16 x 1-1/8" 1 000037001+
Key, Coupling - Tru-Fit 1 119714+
48
Cleanout Plug, SS 2 102298+
56
006-015-018-U3 Seal Guard 2 138896+
61
Name Plate, Sanitary 1 135623+
62
#2 x .187" RHDS 4 30-355
65
Caution Plate 2 121694+
66
Warning Label 2 33-63
67
Grease Fitting, 1/8" 4 LL118404
68
Plastic Cap, Grease Fitting 4 BD0093000
PL5060-CH153
36
45
47
